Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Specifications
Brand Name :
LongJoin
Model Number :
JL-423
Place of Origin :
China
Price :
negotiable
Packaging Details :
Different packaging methods are adopted according to different modes of transport.
Payment Terms :
Western Union,MoneyGram,T/T
Rated Voltage :
120~277VAC
Available Voltage Range :
105~305VAC
Power Consumption :
0.5W Max.
Failure Mode :
C4:Fail-On C5:Fail-Off
Certifications :
RoHS,CE,UL
Real-world Scenarios :
Residential Street Lighting
Description
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature

The JL-423C / JL-423CM Zero-cross+FCC Direct Wire-In Digital Photocontrol is designed for automated control of passage lighting and doorway lighting based on ambient light levels.

This product features electronic circuits with integrated MCU technology. Its quick response with a 5-second time delay offers easy testing while preventing redundant operation from spotlights or lightning during nighttime. The control supports midnight sleeping and reburning before dawn functionality.

The optional Z version incorporates zero-cross technology for extended operational life while conforming to FCC regulations. Additionally, the JL-423CM model provides surge protection up to 235J/5000A.

Product Dimensions
Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Product Features
  • UL773A direct wire-in installation
  • Multi-voltage compatibility
  • Fail-On default with customizable Fail-Off option
  • Optional MOV surge protection
  • IR-filtered phototransistor sensor
  • Customizable night multi-section timing switch
  • IP54 / IP65 protection available with optional rain cap
  • Instant or delayed switching options
Technical Specifications
Model No. JL-423C JL-423CM JL-423CMZ JL-423CL
Rated Voltage 120~277VAC
Available Voltage Range 105~305VAC
Rated Frequency 50/60Hz
Rated Loading 1000W Tungsten 1200VA Ballast @120VAC
1800VA Ballast @208-277VAC
8A e-Ballast @120VAC
5A e-Ballast @208-277VAC
Power Consumption 0.5W Max.
Operate Levels 16Lx Turn-On / 24Lx Turn-Off (customizable)
Time-delay 5-10s (customizable)
Ambient Temperature -40℃ ~ +70℃
Related Humidity 96%
Leads Length AWG #16, AWM 1015 4" min
Failure Mode C4:Fail-On C5:Fail-Off
Surge Protection - 460J/10000A(MOV) - -
Zero Crossing - - ● -
FCC ● ● ● ●
Rainproof Cap Optional
Certifications Zero Cross+FCC Direct Wire In Digital Photocontrol Passage Lighting Time Delay Feature
Frequently Asked Questions
What is a Zero Cross+FCC direct wire in digital photocontrol for passage lighting?
It is a digital photosensor designed specifically for passage lighting systems, featuring direct wire installation, Zero Cross technology for stable operation, FCC certification for electromagnetic compliance, and a built-in time delay function to optimize passage lighting control.
What does Zero Cross technology do in this digital photocontrol?
Zero Cross technology ensures the photocontrol switches on/off at the "zero crossing" of the AC power cycle, reducing electrical arcing, extending the lifespan of connected lighting fixtures, and ensuring smooth, interference-free operation for passage lighting.
Why is FCC certification important for this direct wire photocontrol?
FCC certification means the photocontrol meets strict electromagnetic interference (EMI) and radio frequency interference (RFI) standards, ensuring it does not disrupt other electronic devices and is compliant for use in North American markets.
What is the time delay feature used for in passage lighting photocontrol?
The time delay feature allows the photocontrol to keep passage lights on for a set period after the ambient light level rises (e.g., dawn) or after motion is detected, ensuring safe passage and energy efficiency in hallways, corridors, and other passage areas.
