Specifications
Warranty :
3 years
Brand Name :
LONGDA LED
Model Number :
Small Pitch P0.93 P1.25 P1.56 P1.875
Certification :
CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Place of Origin :
ShenZhen , China
MOQ :
1 Sqm
Price :
Sqm ( price is negotiable )
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
1000sqm per month
Delivery Time :
15 - 18 days
Packaging Details :
Flight case packing or Plywood case packing
Refresh Rate :
3840Hz adjustable
Cabinet Size :
600mm * 337.5mm
Cabinet materia :
Iron cabinet or diecasting aluminum cabinet
Model :
Small Pitch P0.93 P1.25 P1.56 P1.875
Brightness :
600-800nits
Description


Small Pixle Led Display 16:9 Perfect Ratio HD Model P0.9 P1.25 P1.56 P1.875




Product Introduction


1 . Fine Pitch LED Display delivering true-to-life images and videos with high precision pixel pitches,

bringing a great viewing experience to the audience at a close viewing distance.

By providing extraordinary image quality with precise colors,

Fine Pitch LED Display creates remarkable visual experiences that keep constant over time.


2 . 16:9 Golden division ratio

It can be point to point spliced to the led screen of standard 720P ,1080P ,2160P , 3840P ,etc



Specification


Type P0.93 P1.25 P1.56 P1.875
Pitch 0.93mm 1.25mm 1.56mm 1.875mm
Series SMD 600*337.5mm 16:9 Ultra-thin Series
Cabinet Type Die-casting Aluminum
Access / Maintenance Magnet Front Maintenance
LED Model & Type Four in one 1010 1212 1515
LED Make MTC (兆驰) Rayshine Rayshine Rayshine
Refresh 3840Hz adjustable
Brightness 600-800nits
Contrast 5000:1
Viewing Angle H 160°, V 160°
Scan 46s 45s 48s 45s
Density(dot/m²) 1137777 640000 409600 284444
Module Pixels (L*H) 320*180 240*135 192*108 160*90
Module Size (L*H)mm 300*168.75mm
Cabinet Resolution (dot) 230400 129600 82944 57600
Cabinet Size (L*H)mm 600*337.5mm
Cabinet Depth (mm) 22.5
Single Cabinet weight (kg) 3.8
Max Power (watts / m²) 600 500 450 420
Avg Power (watts/m²) 360 300 270 250
Weight (kg/m²) 20
Certification CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Ingress Protection (IP) IP30
Grayscale 14bit
Control mode Synchronous control or Asynchronous control
Operation Temperature - 20 ℃ ～ + 45 ℃
Operation Humidity 10 % ～ 95 %
Life Span 100000h
Compatible Function Double power supply&receive card (One for use,one for back up)





Packing and Shipping:

Packaging and Shipping for Small Pixel LED Display

The Small Pixel LED Display is packed in a cardboard box.
The box is designed to protect the display from dust and other external factors.
The box is sealed with adhesive tape.
The display is shipped using a reliable courier service.
The display is insured against any damage during the shipping process.



16:9 Ratio Small Pitch Led Screen Pixel Display Indoor P0.93 P1.25 P1.56 P1.875  ODM



Service for customers


1.We provide pre-sale service in technical consultation, for example, recommending and designing solutions

as pre the customers request, which help lower the risk of customers investing.

2.In the process of production, gloshine follows up the tightly and accept the supervision from the clients.

Necessary trainings are also provided to the customers.

3.For the after-sale service, Longdaled takes the great responsibility to collect customers feedback,

inspection and maintains products periodically to ensure solving problems timely.
