48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet
48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet
48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet
48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet
48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet
48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet
48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet
48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet
Specifications
Cabinet material :
Iron cabinet or diecasting aluminum cabinet
Model :
Small Pixel Ultra-thin P1.56 full color led display
Brand Name :
LONGDA LED
Model Number :
Small Pixel Ultra-thin P1.56
Certification :
CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Place of Origin :
ShenZhen , China
MOQ :
1 Sqm
Price :
Sqm ( price is negotiable )
Payment Terms :
L / C,T / T,Western Union
Supply Ability :
5000sqm per month
Delivery Time :
15 - 18 days
Packaging Details :
Flight case packing or Plywood case packing
Cabinet Size :
600*337.5mm
Resolution :
192*108
Scan :
48s
Warranty :
3 years
Refresh Rate :
3840Hz adjustable
Brightness :
600-800nits
Description


Small Pixle P1.56 Led Display Panel Led Billboard Die Casting Aluminum Cabinet



Introduction

Pixel pitch led display Excellent Visual Effect.
The images and video visual effects are amazing. Our SP2 series has an excellent visual performance because we adopt high-quality black LED. The color contrast ratio is even better than 5000:1. Armed with HDR technology and color enhancement technology, the white balance of the screen reaches a 100% sRGB and stunning visual performance. Even in high light environments the screen also looks very clear, and the visual effect looks perfect.


48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet



Specifications :


Type P1.56
Pitch 1.56mm
Series SMD 600*337.5mm 16:9 Ultra-thin Series
Cabinet Type Die-casting Aluminum
Access / Maintenance Magnet Front Maintenance
LED Model & Type 1212
LED Make Rayshine
Refresh 3840Hz
Brightness 600-800nits
Contrast 5000:1
Viewing Angle H 160°, V 160°
Control System NovaStar
Scan 48s
Density(dot/m²) 409600
Module Pixels (L*H) 192*108
Module Size (L*H)mm 300*168.75mm
Cabinet Resolution (dot) 82944
Cabinet Size (L*H)mm 600*337.5mm
Cabinet Depth (mm) 22.5
Single Cabinet weight (kg) 3.8
Max Power (watts / m²) 450
Avg Power (watts/m²) 270
Weight (kg/m²) 20
Certification 3C CE ROHS
Ingress Protection (IP) IP30
Grayscale 14bit
Control mode Synchronous control or Asynchronous control
Operation Temperature - 20 ℃ ～ + 45 ℃
Operation Humidity 10 % ～ 95 %
Life Span 100000h
Compatible Function Double power supply&receive card (One for use,one for back up)



48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet


48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet




Functions and Advantages :

1 . High refresh rate : With NOVA STAR control system , no scanning line when photographed ;
2 . High gray level : 256 RGB each , display 16.7M colors , vivid and perfect video effect ;
3 . High resolution : The most apparent features of the new generation of LED display ;
4 . Good color uniformity : With brand Lamp Nationstar and high refresh FM6353 IC .



48 Scan Small Pixel P1.56 Led Display Billboard Kinglight Die Casting Aluminum Cabinet




Your questions
1: LED display models are generally expressed in PX, such as P2 P3 P4.....P8, P10, what does this mean?
A: P1.25, P2, P3 P4.....P8, P10 means that the pixel pitch is 1.25mm, 2mm, 3mm 4mm....10mm,

which determines resolution of a display. Pixel pitch is smaller, led display resolution is higher.

2: To order a display, What kind of information do I have to offer you?
A: You should provide width& height of the display, the main use, the viewing distance, the scene photos,

special requirements, then I can provide you with a detailed list of quotations.

3: How to install?
A: Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram,

free remote debugging. We can also send our engineers to your site to guide the installation if needed.

4: What about the lead time?
A: Orders less than 50 square meter display, lead time is 18-25 working days.

5: Can I order a sample?
A: Yes, your sample orders are welcome, after checking our quality and service,

we are confident that you will come back for your future orders.
