Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast
Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast
Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast
Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast
Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast
Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast
Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast
Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast
Specifications
Cabinet Size :
600mm*337.5mm
Resolution :
240*135
Price :
Usd999 ~ Usd3099 / Sqm
Cabinet Material :
Die-casting Aluminum
Model :
1.25mm
Brand Name :
Longdaled
Model Number :
P1.25
Certification :
CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Place of Origin :
Shenzhen China
MOQ :
1 Sqm
Payment Terms :
T/T
Supply Ability :
5000sqm/month
Delivery Time :
15 - 18 days
Packaging Details :
Flight case packing/ Plywood case packing
Brightness :
600-800nits，adjustable
Scan :
1/45
Warranty :
3 Years
Refresh Rate :
3840Hz
Description

Light Weight Small Pixel Led Screen P1.25 Die-casting Aluminum Indoor Screen For Broadcast



Advantages


1 . Ultra HD : up 409600pixels per square meters , like as HD TV screen with full color
2 .Ultra slim cabinet: the thickness is only 65mm , with fashion configuration design
3 .High strength: made with high quality Die-casting Aluminum cabinet , enhance the heat dissipation ,

and extend the cabinet's working life


Light Weight HD Indoor SMD Fine Pitch Small Pixel LED Display M2 For Broadcast


Product Parameters


Model No

SP0.9

SP1.2

SP1.5

SP1.8

Pixel Pitch

0.9375mm

1.25mm

1.56mm

1.875mm

LED

Mini LED

SMD1010

SMD1010

SMD1515

Module Size(mm)

300*168.75

300*168.75

300*168.75

300*168.75

Module Resolution(dots/)

320 * 180

240 * 135

192 * 108

160 * 90

Pixel Density

1,137,777dots/m²

640,000dots/m²

409,600dots/m²

284,444dots/m²

Cabinet Material

Die cast aluminum

Die cast aluminum

Die cast aluminum

Die cast aluminum

Cabinet Size(mm)

600*337.5*31

600*337.5*31

600*337.5*31

600*337.5*31

Cabinet Weight

3.8kg/cabinet

3.8kg/cabinet

3.8kg/cabinet

3.8kg/cabinet

maintenance method

Front/rear

Front/rear

Front/rear

Front/rear

Support hanging or not

YES

YES

YES

YES

Best Viewing Distance

0.9m

1.2m

1.5m

1.8m

Best Viewing Angle

H:160° W:160°

H:160° W:160°

H:160° W:160°

H:160° W:160°

Max Power consumption

350 W/m²

350 W/m²

350 W/m²

350 W/m²

Average Power Consumption

120 W/m²

120 W/m²

120 W/m²

120 W/m²

Grey Scale

14--16 bits

14--16bits

14--16 bits

14--16 bits

Color Temperature

6500~9000k

6500~9000k

6500~9000k

6500~9000k

Control Method

Synchronous

Synchronous

Synchronous

Synchronous

Refresh Rate

3840 Hz

3840 Hz

3840 Hz

3840 Hz

Brightness(cd/m²)

800-1000

800-1000

800-1000

800-1000

Operating Voltage

110V/220V

110V/220V

110V/220V

110V/220V

Working Humidity

10% - 90%

10% - 90%

10% - 90%

10% - 90%

Working Temperature

-20ºC - 65ºC

-20ºC - 65ºC

-20ºC - 65ºC

-20ºC - 65ºC

Protection Level

IP20

IP20

IP20

IP20




FAQ


1 Reply your inquiry in 24 working hours


2 Experienced staffs answer all your query in fluent English , Spanish , French , German , etc

3 Customized design is available, OEM & ODM are welcomed

4 Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs

5 Special discount and protection of sales area provided to our distributor

6 Warmly welcome your visit in our company if available

7 Guidance service: We can guide on line if customers have questions about the installation and usage
For large project, we provide your engineer a week free training, or if customer could bear the relevant cost,

our engineer can go to customer's country for on-site guidance

8 Warranty period: 2-3 years after shipment
