Specifications
Cabinet Material :
Die-casting Aluminum Cabinet
Model :
Small Pixel P1.56 full color led display
Cabinet size :
600*337.5mm
Resolution :
192*108
Brand Name :
LONGDA LED
Model Number :
Small Pixel P1.56
Certification :
CE / RoHs / FCC / CCC / ISO9001 / ISO14001
Place of Origin :
ShenZhen , China
MOQ :
1 Sqm
Price :
Price is negotiable
Payment Terms :
L / C,T / T,Western Union
Supply Ability :
1000sqm per month
Delivery Time :
15 - 18 days
Packaging Details :
Flight case packing or Plywood case packing
Brightness :
600 - 800 nits
Scan :
48s
Warranty :
3 years
Refresh rate :
3840Hz adjustable
Description

Small Pixel Led Display Used For Conference And Hotel With P1.56 Indoor Wall



Product Introduction:

What is Small Pixel Pitch LED Display?
Our Ultra-Fine Pitch LED Display Series redefines visual excellence with pixel pitches ranging from P1.25 to P2.5, delivering stunning 4K clarity even at close viewing distances.

Featuring advanced technology, our displays offer superior brightness, high refresh rates, and wide color gamuts for optimal performance with both static and dynamic content. Popular for corporate offices, retail spaces, and control rooms, it provides vivid colors, sharp details, and seamless integration.


LONGDA Small Pixel Led Display P1.56 Indoor Full Color Conference Video Wall ISO9001



Specifications :


Type P1.56
Pitch 1.56mm
Series SMD 600*337.5mm 16:9 Ultra-thin Series
Cabinet Type Die-casting Aluminum
Access / Maintenance Magnet Front Maintenance
LED Model & Type 1212
LED Make Rayshine
Refresh 3840Hz adjustable
Brightness 600-800nits
Contrast 5000:1
Viewing Angle H 160°, V 160°
Scan 48s
Density(dot/m²) 409600
Module Pixels (L*H) 192*108
Module Size (L*H)mm 300*168.75mm
Cabinet Resolution (dot) 82944
Cabinet Size (L*H)mm 600*337.5mm
Cabinet Depth (mm) 22.5
Single Cabinet weight (kg) 3.8
Max Power (watts / m²) 450
Avg Power (watts/m²) 270
Weight (kg/m²) 20
Certification 3C CE ROHS
Ingress Protection (IP) IP30
Grayscale 14bit
Control mode Synchronous control or Asynchronous control
Operation Temperature - 20 ℃ ~ + 45 ℃
Operation Humidity 10 % ~ 95 %
Life Span 100000h
Compatible Function Double power supply&receive card (One for use,one for back up)



LONGDA Small Pixel Led Display P1.56 Indoor Full Color Conference Video Wall ISO9001



Packing and Shipping:

Packaging and Shipping for Small Pixel LED Display

The Small Pixel LED Display is packed in a cardboard box.
The box is designed to protect the display from dust and other external factors.
The box is sealed with adhesive tape.
The display is shipped using a reliable courier service.
The display is insured against any damage during the shipping process.



LONGDA Small Pixel Led Display P1.56 Indoor Full Color Conference Video Wall ISO9001




FAQ :

1 . Reply your inquiry in 24 working hours ;

2 . Experienced staffs answer all your query in fluent English , Spanish , French , German , etc ;
3 . Customized design is available , OEM & ODM are welcomed ;
4 . Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs ;
5 . Special discount and protection of sales area provided to our distributor ;
6 . Warmly welcome your visit in our company if available ;
7 . Guidance service : We can guide on line if customers have questions about the installation and usage ,
for large project , we provide engineer for a week free training , or if customer could bear the relevant cost ,

our engineer can go to customer' s country for on - site guidance ;
8 . Warranty period : 3 years after shipment .
