P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums
P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums
P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums
P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums
P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums
P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums
P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums
P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums
Specifications
Cabinet Material :
Die-casting Aluminum
Cabinet Size :
640mmx480mm/500mmx500mm
Resolution :
128*64/84*84
Model :
2.5mm/ 3mm
Brightness :
600~1000nits
Brand Name :
Longdaled
Model Number :
P2.5 P3 Indoor led screen
Certification :
CE/ RoHs/ FCC/ CCC/ ISO9001/ ISO14001
Place of Origin :
Shenzhen, China
MOQ :
1 Sqm
Price :
Price is Negotiable
Payment Terms :
T/T
Supply Ability :
1000sqm per month
Delivery Time :
15-18 days
Packaging Details :
Flight case packing/ Plywood case packing
Scan :
1/32
Warranty :
3 Years
Refresh Rate :
3840~7680Hz
Description

Small Pixel Pitch P2.5 P3 LED Display Indoor Stage Led Screen For Event Auditoriums



Advantages


1 . Indoor Small Pixel Pitch P2.5 P3 led screen with high resolution and high definition,

widely used for conference, plaza, office, party, church, DJ bar, club, concert stage and so on;


2 . With ultra slim cabinet, the thickness is only 65mm, with fashion configuration design;


3 . Made with high quality die-casting aluminum cabinet, enhance the heat dissipation,

and extend the cabinet's working life.


P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums


Product Parameters



Item

Specification

Pixel Pitch

2.5mm

3mm

Module Resolution

W128×H64dots

84*84dots

Module Size

320*160mm

250*250mm

Led Packing

2121

IP Rate

43

IC

5124

LED composition

1R1G1B

1R1G1B


P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums


Cabinet Size

640*480mm

500*500mm

Module Qty

W2× H3=6PCS

2*2=4pcs

Physical Resolution

W256×H192dots

W168*168dots

Power Consumption(MAX.)

320W/m²

Power Consumption(AVE.)

96W/m²

Cabinet Material

Die-casting Aluminum

Physical Density

160000 dots/m²

111000dots/m²

Net Weight

9Kg

6.5kg


P2.5 P3 Small Pixel LED Display Indoor Stage LED Screen For Event Auditoriums


Colors

16.7 trillion

Brightness Control

Software 256 level adjustable

Gray Level

16

View Distance

3～30m

Refresh Rate

7680hz

Control mode

Synchronous control or Asynchronous control

Frame Frequency

≥60Hz

Certification

CE/ROHS/FCC/CCC/ISO9001/ISO14001

Operation Temperature

-20℃ ～ +45℃

Operation Humidity

10%～95%




FAQ


1 Reply your inquiry in 24 working hours;


2 Customized design is available, OEM & ODM are welcomed;

3 Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs;

4 Warranty period: 2-3 years after shipment;

5 Special discount and protection of sales area provided to our distributor;

6 Warmly welcome your visit in our company if available;

7 Guidance service: We can guide on line if customers have questions about the installation and usage,
For large project, we provide a week free training to your engineer, or if customer could bear the relevant cost,

our engineer can go to customer's country for on-site guidance.
