4.5A 3.7 V 3000mah Lipo Battery Lightweight Long Cycle Life Battery OiD585085-3000
4.5A 3.7 V 3000mah Lipo Battery Lightweight Long Cycle Life Battery OiD585085-3000
4.5A 3.7 V 3000mah Lipo Battery Lightweight Long Cycle Life Battery OiD585085-3000
4.5A 3.7 V 3000mah Lipo Battery Lightweight Long Cycle Life Battery OiD585085-3000
Specifications
Brand Name :
OiD
Model Number :
OiD585085-3000
Certification :
Compliant with GB/T 18287-2013, IEC/EN61960, and UL1642 standards. RoHS compliant.
Place of Origin :
China
MOQ :
100pcs
Name :
3.7 V 3000mah Lipo Battery
Battery Type :
3.7V, 3000mAh Rechargeable
ODM :
Free custom design for packs
Flexible Form Factor :
Thin, Customizable Pouch Design Lithium Ion Battery
High Energy Density :
250-300Wh/kg
Superior Cold Weather Performance :
Reliable in Extreme Cold (-20°C to 60°C)
Cycle Life :
500+ cycles
Charging/ Discharging :
1C/ 1.5C
Price :
$0.5 ~ $100.0 / pcs
Delivery Time :
3 ~ 7 days for storage
Payment Terms :
TT, L/C, Western Union
Description

OiD585085-3000 3.7V 3000mAh Lithium Polymer Battery 4.5A Max Discharge 500 Cycles

Product Name:

OiD585085-3000 Lithium Polymer Battery

Advantages:

  • High energy density for extended usage.
  • Lightweight and compact design.
  • Enhanced safety features including overcharge, over-discharge, and short-circuit protection.
  • Long cycle life with consistent performance.
  • Environmentally friendly and RoHS compliant.

Specifications:

Parameter

Details

Model

OiD585085-3000

Nominal Voltage

3.7V

Capacity

3000mAh (0.2C discharge)

Charging Voltage

4.2V

Discharge Cut-off Voltage

3.0V

Standard Charging Current

0.2C

Max Charging Current

1.0C (Continuous 0.5C charging)

Max Discharging Current

1.5C (Continuous 1.0C discharging)

Weight

Approx. 53.0g

Shipment Voltage

3.90±0.05V

Battery Impedance

≤150mΩ

Max Charge Current (Temp)

0°C~10°C: 0.2C max,

10°C~20°C: 0.5C max,

20°C~45°C: 1.0C max

Max Discharge Current (Temp)

-20°C~0°C: 0.2C max,

0°C~25°C: 1.0C max,

25°C~60°C: 1.5C max

Cycle Life:

Cycle Condition

Performance

Charge/Discharge Cycles

500 cycles at 0.2C charge/discharge at 23±2℃

Capacity Retention

≥80% after 500 cycles

Discharge Curve:

4.5A 3.7 V 3000mah Lipo Battery Lightweight Long Cycle Life Battery OiD585085-3000

Operating Temperature Range:

Condition

Temperature Range

Charging

0°C to 45°C

Discharging

-20°C to 60°C

Storage (50% SOC)

-10°C to 25°C (12 months, ≥85% capacity),

-10°C to 45°C (6 months, ≥85%),

-10°C to 55°C (1 month, ≥90%)

Certifications:

  • Compliant with GB/T 18287-2013, IEC/EN61960, and UL1642 standards.
  • RoHS compliant.

Key Features:

  • PTC Protection: Prevents overcurrent and overheating.
  • NTC Thermistor: Monitors temperature for safe operation.
  • Durable Plastic Case: ABS+PC material for enhanced durability.
  • High-Quality Connector: JST-GHR-05V-S for reliable connections.
  • Rubber Grommet: Withstands up to 5 lbs (2 kg) of pull force.

Applications:

  • Portable electronic devices.
  • Medical equipment.
  • Power tools.
  • IoT devices.
  • Consumer electronics.

4.5A 3.7 V 3000mah Lipo Battery Lightweight Long Cycle Life Battery OiD585085-3000

Usage Warnings & Precautions:

  • Use only with the specified charger.
  • Avoid short-circuiting the battery terminals.
  • Do not expose the battery to high temperatures or fire.
  • If the battery shows signs of swelling, leakage, or damage, discontinue use immediately.
  • Keep away from children and pets.

Storage Guidelines:

  • Store at 20±5°C for optimal performance.
  • Maintain a charge level of 50% for long-term storage.
  • Recharge every 3 months if not in use to maintain battery health.

Warranty & Disclaimer:

  • Warranty: 12 months from the date of shipment.
  • Disclaimer: Any misuse or failure to follow the guidelines will void the warranty.
