Satellite Positioning Antenna Helical Spiral Transmitting Multi-band Beidou GLONASS GPS GNSS Antenna

1. Specification

A. Electrical Characteristics
Frequency 1197-1278MHz; 1559-1606MHz
Supported Positioning signal bands

GPS: L1/L2

BDS: B1/B2/B3

GLONASS: G1/G2

Galileo: E1/E5b
Peak Gain ≥2dBi
Impedance 50Ohm
Polarization RHCP
Axial Ratio ≤1.5 dB
Azimuth Coverage 360°
B. LNA and Filter Electrical Properties
LNA Gain 35±2dBi(Typ.@25℃)
Noise Figure ≤1.5dB@25℃,Typ.(Pre-filtered)
Output VSWR ≤1.8 : 1Typ. 2.0 : 1 Max
Operation Voltage 3-16 V DC
Operation Current ≤45mA
C. Material & Mechanical Characteristics
Connector Type SMA connector
Dimension Φ27.5x56mm
Radome material PC+ABS
Waterproof IP67
Weight 0.018Kg
C. Environmental
Operation Temperature - 40 ˚C ~ + 85 ˚C
Storage Temperature - 40 ˚C ~ + 85 ˚C
Humidity ≤95%

2. Antenna - S Parameter Test Data

2.1 VSWR

Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS

2.2 LNA Gain:

Frequency (MHz) Gain (dBi) Frequency (MHz) Gain (dBi)
1195.0 30.91 1555.0 32.22
1200.0 32.02 1560.0 34.14
1205.0 33.15 1565.0 35.37
1210.0 34.27 1570.0 35.14
1215.0 35.11 1575.0 34.94
1220.0 35.80 1580.0 34.90
1225.0 36.40 1585.0 35.00
1230.0 36.74 1590.0 34.61
1235.0 36.57 1595.0 34.88
1240.0 35.82 1600.0 32.42
1245.0 34.49 1605.0 31.26
1250.0 33.07 1610.0 31.52
1255.0 31.59
1260.0 30.45
1265.0 29.47
1270.0 28.61
1275.0 27.93
1280.0 27.51
2.3 Radiation Pattern
3D 2D-Horizontal 2D-Vertical
1195MHz Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS
1235MHz Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS
1280MHz Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS
3D 2D-Horizontal 2D-Vertical
1555MHz Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS
1585MHz Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS
1610MHz Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS Multiband Gps Antenna Helical Spiral Transmitting Beidou GLONASS GPS GNSS
