P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
Specifications
Brand Name :
Shenzhen LED World
Model Number :
LW-RI 3.91
Certification :
CE,RoHS,FCC
Place of Origin :
China
MOQ :
1 square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1,000 square meters per month
Delivery Time :
10-18 working days after received your payment
Packaging Details :
Plywood cartons or Flight case package
Pixel type and configuration :
3-in-1 SMD
Brightness control :
256 Levels
Input power (max) :
300 Watts / panel.
Dot per sq. meter :
65,536
Recommended best viewing distance :
3~100 m
Display refresh rate :
180~3,000 Hertz
Red wavelength (dominant) :
620~625 nm
Multimedia data format :
DVI,MPG,AVI,WMV,RM etc.
Description

indoor&outdoor rental 500x500mm-P3.91,P4.81,P5.95,...

P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20

Features:

  • Indoor and outdoor Full color led project screen.
  • Adjustable screen radian;
  • 500x500mm panel size is given it the advantage of setting up accurate dimensions;
  • High definition,43402 Pixels/sqm,can show extremely clear and vivid video,images and texts,looking very high end;
  • Can be flat screen and curved screen, one screen, multiple use, you can shape anything you want;
  • Mixed installation: the two cabinets size of 500mmx500mm and 500mmx1000mm can be installed together;
  • The same cabinet can be compatible with different pitches:P4.8/P3.91/P6.25Some pictures showing as belo for your reference:Some pictures showing below for your reference;
  • Angle adjustable -20 degree to +20 degree, inside curved or outside curved both available;

Application:

Wide applied in plaza,entertainment TV,power sector,monitoring centers,banking,Entertainment complexes,hotel and so on .

Our service:

  • ​Well-trained and experienced staffs to answer all your enquires in fluent English;
  • 2 years warranty offered;
  • We only offer the drawings, and you can show the drawing to your local steel structure factory, and they will weld it for you at site. On one hand, it's not cost-effective for you to ship the steel structure from China. On the other hand, we are impossible to offer you exact steel structure without welding at site;

Parameter:

Parameter Unit Value
Pitch mm 3.91
Brightness nits 1,500
Color temperature deg. K 6,500
Viewing angle - Horizontal (50% brightness) deg. 140(-70 ~ +70)
Viewing angle - Vertical (50% brightness) deg. 140(-70 ~ +70)
Panel weight kg 6
Panel width mm 500
Panel height mm 500
Panel depth mm 78
Panel area sq. m. 0.25
Panel material 　 Epoxy paint coated Aluminum
Panel Mode 　 Die-Cast rental
Operating temperature range deg. C -20 to +60
Humidity operating RH 10% ~ 60%
Pixel type and configuration R/G/B 3-in-1 SMD
Resolution per panel 　 128x128
Dot per panel 　 16,384
Dot per sq. meter 　 65,536
LED per sq. meter 　 65,536
Recommended minimum viewing distance m 2.98
Recommended best viewing distance m 3~100
Colors 　 281 Trillion
Grey scale (linear) Levels 65,536
Brightness control Levels 256
Contrast ratio 　 2,000:1
Processing depth bit 16
Video frame rate Hertz 60
Display refresh rate Hertz 180~3,000
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts / panel. 300
Input power (typical) Watts / panel. 120
Lifetime (50% brightness) Hours ≥100,000
Red wavelength (dominant) nm 620~625
Green wavelength (dominant) nm 520~525
Blue wavelength (dominant) nm 470~475
Multimedia data format 　 DVI,MPG,AVI,WMV,RM etc.
Data interconnection 　 UTP Cat 5/Optical Fiber
Mounting system 　 Hanging/Fixed
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Product detail:

P3.91 P4.81 P5.95 P6.25 Portable stage video screens angle adjust -20 to +20
