SMD2121 LED Stage Display Ultra Slim P3 Indoor Screen Installed In Church
SMD2121 LED Stage Display Ultra Slim P3 Indoor Screen Installed In Church
SMD2121 LED Stage Display Ultra Slim P3 Indoor Screen Installed In Church
SMD2121 LED Stage Display Ultra Slim P3 Indoor Screen Installed In Church
SMD2121 LED Stage Display Ultra Slim P3 Indoor Screen Installed In Church
SMD2121 LED Stage Display Ultra Slim P3 Indoor Screen Installed In Church
Specifications
Brand Name :
Shenzhen LED World
Model Number :
LW-RI 3
Certification :
CE,RoHS,FCC
Place of Origin :
China
MOQ :
1 square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1,000 square meters per month
Delivery Time :
10-18 working days after received your payment
Packaging Details :
Plywood cartons or Flight case package
Screen thickness :
85mm
Working voltage :
AC220V/110V±10%
Max.Power consumption :
≤360W/ m2
Refresh frequency :
≥2200HZ
Pixel per cabinet :
192*192
Best viewing distance :
160°(W) 120°(H)
Scan mode :
1/16scan
Package mode :
SMD2121
Pixel pitch :
3mm
Description

indoor rental 576mmx576mm-P3,P6.pdf

Ultra Slim P3 LED stage Display indoor screen installed in church

P3 LED stage Display indoor screen features:

  1. High Contrast ratio (5000: 1) with a black mask and black coating technique;
  2. Large viewing angle,160 degrees Horizontally and 140 degrees vertically by using our specially designed mask;
  3. Die-castingAluminumstructure,high-precision processing technology, and good heat dissipation;
  4. High contrast rate by using blackbody LED, a reach 9000:1;
  5. With special rigging system, It is very convenient to hang the screen to the truss. It is very safe;
  6. HIgh refresh rate 1500-2000HZ/S, guarantee no scanning lines when taken photo or video;

LED stage Display indoor screen parameter:

Module Model Number P3mm
Module size 192mm*96mm
Pixel pitch 3mm
Pixels Density 111111 /m2
Pixel configuration 1R1G1B
Package mode SMD2121
Pixel resolution 64dots(W)*32 dots(H)
Scan mode 1/16scan
Port type HUB75-A
Brightness ≥1800cd/m2
Cabinet Cabinet size 576mm*576mm
Electricity parameters Power supply 5V/40A*3pcs
Pixel per cabinet 192*192
Best viewing distance 3M ~ 20M
Best viewing distance 160°(W) 120°(H)
Temperature -40 degree~ +70 degree
Relative humidity 10%-95%
Screen thickness 85mm
Working voltage AC220V/110V±10%
Average Power 180W/ m2
Max.Power consumption ≤360W/ m2
Refresh frequency ≥2200HZ
Grey scale/color 256levels of each color (RGB)/16.7M colors
MTBF ≥9000hours
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Application:

Now, with the development of society, the led screen has been used in many areas, mainly divided into outdoor usage and indoor usage such as:indoor performance, indoor rental business, Public places, Business usage;For example: supermarket, restaurants, travelling agency, commercial plaza, Movie theaters,clubs, commercial building, subway stations, airport stations,

FQA:

Q1: What s your delivery time?
A1: Within 7-21 days after we receiving the deposit
Q2: Except this model, are there any other models?
A2: yes, For indoor led screen we have p2.5 p3 p3.91 p4 p4.81 p5 p6 p7.62 p10 For outdoor led screen we have p5 p6 p8 p10
Q3: How is your service?
A3: 1 We offer 2-3 years warranty Lifetime free maintenance and upgrade;

2 Full set of documents free of charge which including installation guidance software operation manual

easy maintenance manual and control system software CD and soon;
3 Complaint respond period not exceed 1 working day;
4 Free technician training can be offered either when you are in our factory for inspection the goods or via remote control.
Q4: What s the function of your led screen?
A4: It supports videos, flash, WAV/MIDI, PPT, images and so on

Product detail:

SMD2121 LED Stage Display Ultra Slim P3 Indoor Screen Installed In Church
