Specifications
Brand Name :
Shenzhen LED World
Model Number :
LW-RI 5
Certification :
CE,RoHS,FCC
Place of Origin :
China
MOQ :
1 square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1,000 square meters per month
Delivery Time :
10-18 working days after received your payment
Packaging Details :
Plywood cartons or Flight case package
Density :
40000dots/sq.m
Material of Cabinet :
Die-casting Aluminum
Pixel Configuration :
1R1G1B
Brightness :
>1300cd/sq.m
Size of module :
160mm x 160mm
Resolution of cabinet :
96x96
MTBF :
10,000 hours
Resolution of module :
32x32
Description

indoor rental 480x480mm- P2.0,P2.5,P5.pdf
5mm pixel pitch led indoor display stage Tri-color HD Dynamic screen wall

Features:

  • Back cover can be opened without any tools and modules can be taken off without dismantlement of power supply, much more convenient for examination and maintenance;
  • Two patent protected strong locks design,realizing combination of reliablity and security;
  • Innovative handle
  • Handle is innovative, grip and wide for easy handling.
  • Strong Locks for hanging installation
  • The cabinets locks are smooth edged, easy handling and strong that you can hang up 20 pcs cabinet in vertical column;
  • Auto vertical lock system easier and faster installation and disassembling;
  • Fast Installation and disassembling: connection lock between cabinets are patented, closely combined, safe, reliable and adjustable, 50 cabinets can be installed in one hour;
  • Fast setting-up design;
  • With fast locks,easy to install and dismantle;
  • Small size cabinet unit , relatively light body . Easy for shipping and installing;

Our service:

  • Apart from the advertising LED display ,we also suport indoor/outdoor SMD LED display /LED gas price sign /Flexible LED sign /LED pharmacy cross;
  • Reply your email or inquiry within 12 hours;
  • We offer training for free;
  • We promise you more than just two years warranty service;
  • OEM&ODM, any your customized display we can help you to design and put into product;
  • We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service;
  • We promise a life time follow-up service for all the equipment supply by our company. These include continuously improve of system functions and upgrade of system software;
  • Monthly production capacity: 3000 Sq. M;



Application:
It can be widely used in stage shows,TV-Show,Entertainment centers,motor racing Circuits, Entertainment complexes,securities exchange,government,surrounding,large entertainment plaza,chain shop,bookstore,
exclusive agency,concert hall,Shopping area and so on.




Parameter:

Pixel pitch5.0mm
Pixel Configuration1R1G1B
LED componentSMD3528
Size of module160mm x 160mm
Resolution of module32x32
Size of cabinet480mm x 480mm x 78mm
Resolution of cabinet96x96
Material of CabinetDie-casting Aluminum
Weight of Cabinetabout 7KG/cabinet
Brightness>1300cd/sq.m
Density40000dots/sq.m
Best viewing angle120 /120
Best viewing distance5-15M
Maximum power consumption600W/sq.m
Average power consumption300W/sq.m
Driving method1/16 scan or 1/8 scan
Control methodSynchronization
Gray scale4096
Colors256*256*256
Working voltageAC220V/110V±10%
Working temperature-20ºC~+50ºC±10%
Working humidity10% ~ 90%
MTBF10,000 hours
Frame frequence50/60Hz
Refresh frequence>3000Hz
IP gradeIP31
Life Span100,000 hours
Data transafer methodRJ45
Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.


Product detail:
Convenient Led Stage Curtain , Tri Color Led Display Rental 40000dots/Sq.M

Convenient Led Stage Curtain , Tri Color Led Display Rental 40000dots/Sq.M
