Specifications
Brand Name :
Shenzhen LED World
Model Number :
LW- FO 10
Certification :
RoHS,FCC,CCC,CE
Place of Origin :
China
MOQ :
1 pcs
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5000 pcs/month
Delivery Time :
10~18 working days after deposit received
Packaging Details :
Plywood case
Driving method :
1/4 scan
Working voltage :
AC220V±10%
Data transafer method :
RJ45
Best viewing angle :
110 /50
Pixel pitch :
10mm
Brightness :
>7500cd/sq.m
Screen area :
65.13sq.m
Best viewing distance :
8-150M
Description

P10 / P8 / P6 / P5 truck led display electronic digital billboard on trailer for advertising

Features:

  • Waterproof module with enclosed structure;
  • With dip 346 epsitar chips is a tradintional products,with steady technology and good performance for outdoor display, especially with cheap price;
  • Easy front-maintenance module is convenient for disassembly and assembly;
  • Online power backup to ensure normal work;
  • Self-adjusting intelligent brightness system.brightness of the screens can be adjusted intelligently;
  • the world's first high efficiency and energy saving, the maximum energy saving 70%, save the cost;
  • Back installation for drivers,benefical to maintenance；

​Parameter:

P10 DIP Outdoor full Color LED Screen Specification for one screen
Pixel pitch 10mm
Screen area 65.13sq.m
Resolution of one screen 6784 x 96dots
Size of module 160mm x 160mm
Resolution of module 16x16
Size of cabinet 1280mm x 960mm x 200mm
Resolution of cabinet 128x96dots
Number of Cabinets 53 pcs
Weight of Cabinet <80KGS
Brightness >7500cd/sq.m
Density 10000dots/sq.m
Best viewing angle 110 /50
Pixel Configuration 1R1G1B
Best viewing distance 8-150M
Maximum power consumption <800W/sq.m
Driving method 1/4 scan
Control method Synchronization
Gray scale 16 bits
Colors 16777216
Color temperature 6500k
Working voltage AC220V±10%
Working temperature -20ºC~+50ºC±10%
MTBF >10,000 hours
Frame frequence ≥60Hz
Refresh frequence >1800Hz
IP grade(Front/Back) IP65/IP54
Life Span 100,000 hours
Data transafer method RJ45
Effectivce Communication Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Distance(without relay) Single-mode optic fiber: 10KM
Systems operating platform WINDOWS(WIN95,WIN2000,WINXP,WIN7/8), and interfaces for secondary development
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Applications:

It can be widely used in Lobby,cinema, bar, entertainment venues,train station,motor racing Circuits, large exhibition hall,Convenience Stores,chain shop and so on .

Our service:

  • If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc;
  • Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees;
  • Training in our factory offered FOC;
