76PPI 10.4 TFT LCD Monitor Display 640x480 VGA NL6448BC33-70 NEC
76PPI 10.4 TFT LCD Monitor Display 640x480 VGA NL6448BC33-70 NEC
76PPI 10.4 TFT LCD Monitor Display 640x480 VGA NL6448BC33-70 NEC
76PPI 10.4 TFT LCD Monitor Display 640x480 VGA NL6448BC33-70 NEC
Specifications
Place of Origin :
China
Brand Name :
NEC
Price :
$165/pieces 1-99 pieces
Model Number :
NL6448BC33-70
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Delivery Time :
3-5 working days
Packaging Details :
10pcs/Box
Panel Type :
a-Si TFT-LCD, LCM
Display Size :
10.4inch
Brand :
NEC
Supplier Type :
Original Brand
Resolution :
640(RGB)×480, VGA 76PPI
Module Outsize(mm) :
243(H)x185.1(V) x11(D) mm
Viewing Angle :
80/80/80/80 (Typ.)(CR≥10)
Brightness :
450cd/m2
Contrast Ratio :
900:1 (Typ.) (TM)
Interface :
CMOS (1 ch, 6-bit) , 31 pins Connector
Touch panel :
Withtout
Application :
Industrial Equipment
MPQ :
10pcs
Warranty :
12 Months
Description
NLT NL6448BC33-70 10.4-Inch VGA TFT-LCD Industrial Display
High-performance 10.4-inch TFT-LCD display module with 640×480 VGA resolution, engineered for demanding industrial applications requiring reliable operation across wide temperature ranges.
Note: This product has reached end-of-life (EOL). Limited stock available - please order promptly.
Key Features
  • 640×480 VGA resolution with 76 PPI for clear display
  • 450 cd/m² high brightness for excellent visibility
  • TN technology with 80/80/65/80 viewing angles
  • LVDS interface with 20-pin connector for reliable data transmission
  • 800:1 contrast ratio for superior image quality
  • WLED backlight with 50,000 hours lifespan
  • 262K color support with 50% NTSC color gamut
  • Wide operating temperature range: -30°C to 80°C
  • Vibration Level: 2.0G (19.6 m/s²)
Technical Specifications
Panel Model NL6448BC33-70 Panel Brand NEC
Size 10.4 inch Panel Type a-Si TFT-LCD, LCM
Resolution 640(RGB)×480, VGA 76PPI Pixel Format RGB Vertical Stripe
Module Dimensions 243(W)×185.1(H)×11(D) mm Display Mode TN, Normally White, Transmissive
Active Area 211.2(W)×158.4(H) mm Response Time 3/15 (Typ.)(Tr/Td)
Display Colors 262K 40% NTSC Light Source WLED [3 strings], 70K hours, W/O Driver
Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Touch Screen Without
Brightness 450 cd/m² (Typ.) Power Supply 3.3/5.0V (Typ.)
Contrast Ratio 900:1 (Typ.) (TM) Application Industrial
Frame Rate 60Hz Storage Temperature -30 ~ 80 °C
LCM Interface Type CMOS (1 ch, 6-bit), 31 pins Connector Operating Temperature -30 ~ 80°C
FPC Connector HRS, DF9C-31P-1V, Pitch 1.0mm Vibration Level 2.0G (19.6 m/s²)
Applications
  • Industrial equipment and machinery
  • Automation equipment displays
  • CNC machine displays
  • Medical equipment
  • EV Charger Display
  • Industrial Control Display
Customization Options
This display can be equipped with an HDMI driver board for easier debugging and evaluation, as well as for direct integration into your products.
