LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
LQ104V1DG81 Original Industrial Sharp 10.4 Inch TFT-LCD Display Screen with 640x480 VGA Resolution and Wide Temperature Range
Specifications
Place of Origin :
China
Brand Name :
Sharp
Price :
$150/pieces 1-99 pieces
Model Number :
LQ104V1DG81
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Delivery Time :
3-5 working days
Packaging Details :
20pcs/Box
Panel Type :
a-Si TFT-LCD, LCM
Display Size :
10.4inch
Supplier Type :
Original Brand
Module Outsize(mm) :
246.5(H)x179.3(V) x13(D) mm
Resolution :
640(RGB)x480, VGA 76PPI
Viewing Angle :
80/80/60/80 (Typ.)(CR 10)
Brightness :
450cd/m2
Interface :
CMOS (1 ch, 6-bit) , 31 pins Connector
Touch Screen :
Without
Light Source :
WLED , 50K hours , With LED Driver
Environment :
Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C
MPQ :
20pcs
Application :
Industrial
Warranty :
12 Months
Description
Original Industrial Sharp LQ104V1DG81 10.4 Inch Display
High-performance 10.4-inch TFT-LCD display panel with VGA 640×480 resolution, designed for demanding industrial applications requiring reliable visual performance in wide temperature environments.
Product Status: This model started mass production in Q1 2012 and has been discontinued. The stock is limited,please contact us if you need.
Key Features
  • 640×480 VGA resolution with 76 PPI for clear imagery
  • 450 cd/m² brightness display for excellent visibility
  • TN technology with 80/80/65/80 viewing angles
  • CMOS interface with 31-pin connector for reliable data transmission
  • 800:1 contrast ratio for superior image quality
  • WLED backlight with 50,000 hours lifespan
  • 262K color support with 50% NTSC color gamut
  • Wide operating temperature range: -30°C to 80°C
Technical Specifications
Panel Model LQ104V1DG81 Panel Brand Sharp
Size 10.4 inch Panel Type a-Si TFT-LCD, LCM
Resolution 640(RGB)×480, VGA 76PPI Pixel Format RGB Vertical Stripe
Module Dimensions 246.5(H)×179.3(V)×13(D) mm Display Mode TN, Normally White, Transmissive
Active Area 211.2(W)×158.4(H) mm Response Time 35ms (Typ.)
Display Colors 262K, 50% NTSC Light Source WLED, 50K hours, With LED Driver
Viewing Angle 80/80/65/80 (Typ.)(CR≥10) Touch Screen Without
Brightness 450 cd/m² (Typ.) Power Supply 3.3V (Typ.)
Contrast Ratio 800:1 (Typ.) Application Industrial
Frame Rate 60Hz Interface Type CMOS (1 ch, 6-bit), 31 pins Connector
Operating Temperature -30°C to 80°C Storage Temperature -30°C to 80°C
FPC Connector HRS, DF9MA-31P-1V(32), Pitch 1.0mm
Applications
  • Industrial equipment and machinery
  • Elevator Display
  • Security Monitor Display
  • Automation Equipment Display
  • CNC Machine Display
Customization Options
Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include AR (Anti-Reflective), AF (Anti-Fingerprint), and AG (Anti-Glare). Can be equipped with HDMI driver boards for simplified customer debugging and evaluation.
