Hollow Glass UV Irradiation Detector Tester Ultraviolet Radiation Detector
Hollow Glass UV Irradiation Detector Tester Ultraviolet Radiation Detector
Hollow Glass UV Irradiation Detector Tester Ultraviolet Radiation Detector
Hollow Glass UV Irradiation Detector Tester Ultraviolet Radiation Detector
Hollow Glass UV Irradiation Detector Tester Ultraviolet Radiation Detector
Hollow Glass UV Irradiation Detector Tester Ultraviolet Radiation Detector
Specifications
Model Number :
ZW-F
Power supply/power :
AC: 220V/1.8KW
Time setting range :
0~300h
Cooling plate material :
copper
Lead Time :
15 days
Temperature Range :
-70°C to 150°C
Package :
Standard and strong wooden case
Description

Hollow Glass UV Irradiation Detector Tester Ultraviolet Radiation Detector
1. Introduction
I. Use
ZW-F ultraviolet radiation detector is designed and manufactured according to the technical requirements of national standard GB/T11944-2012<< insulating glass >>, used to test the ability of insulating glass to resist ultraviolet radiation.
Principle of operation
Install UV lamp in the closed test box, the glass sample in the appropriate place in the box, to accept ultraviolet radiation, in the other side of the sample close contact with the cooling plate, cooling plate by tap water cooling, test whether the hollow glass after ultraviolet irradiation in the cooling plate fog, oil or other contaminants, to determine the resistance to ultraviolet radiation performance of the hollow glass.

2. Technical Parameters

Temperature in the test chamber + 3 ºC to 50 ºC
Power supply/power AC: 220V/1.8KW
Cooling plate material copper
Cooling plate material copper
Light source output power > 40W/m2
Distance between the center of the sample and the light source 300mm
Test light source Uv lamp MLU 300W
Water temperature at inlet and outlet of cooling tray 16 ºC + 2 ºC
Time setting range 0~300h
Working environment temperature No less than 20ºC
