Specifications
Place of Origin :
Guangdong, China
Brand Name :
LONROY
MOQ :
1
Temperature range :
-70°C to 150°C
Humidity range :
20%~98% R.H.
Temp accuracy :
±0.5°C
Humidity accuracy :
±2.5%
Heating rate :
4.0°C/min
Cooling rate :
1.0°C/min
Inner material :
SUS#304 Stainless steel
Outer material :
Carton Advanced cold plate nano paint
Insulation material :
High density foam
Cooling system :
Air cooling/single segment compressor
Voltage :
220V, 380V
Power supply :
AC220V 50/60Hz & 1, AC380V 50/60Hz 3
Protection class :
IP56
Compressor brand :
Tecumseh
Controller type :
TATO Taiwan
Description

CE ISO 9001 Climate Chamber Temperature Humidity Test Machine Programmable High and Low Temperature Environmental Chamber

Product Description

Introduction

The Climate test chamber is a precise and durable conditioning system that able to offer quick and constant conditions from 5% to 98% R.H. +/- 0.5% and-70°C to 150°C +/-0.5°C, is widely used for the resistance test to heat, cold, dry, and humidity etc, and used for the conditioning of many kinds of samples prior to testing
It is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, suitable for quality control of the industries of electron, electrical equipment, vehicle, metal, foodstuffs, chemistry, building materials, luggage, adhesion tape, printing, packaging, etc.

Climate Test Chamber with different size and temperature range customization
1.LCD touch screen
2.Inner material:SUS#304
3.Tato controller, with Independent R &D software (7 languages)
4.Teme. Range: -70~150/180C adjustable

Accessories
Inner door with operation hole (optional)
50mm or 100mm Entrance hole for test wire, Dia. 50mm or 100mm
Sample Shelves, two layers or more
R232 or R485 communication Interface for remote control

OEM customization available
High cost-effective
CE, RoHS, FCC Marked Equipment,
ISO 9001 certificated
SGS tested SUS#304 stainless steel

CE ISO 9001 Climate Chamber Temperature Humidity Test Machine Programmable High and Low Temperature Environmental Chamber

Technical Specification

Model

LR-HS-80
(A~F)

LR-HS-150
(A~F)

LR-HS-225
(A~F)

LR-HS-408
(A~F)

LR-HS-800
(A~F)

LR-HS-1000
(A~F)

Inner size: WHD(cm)

40*50*40

50*60*50

60*75*50

60*85*80

100*100*80

100*100*100

External size: WHD(cm)

105*165*98

105*175*108

115*190*108

135*200*115

155*215*135

155*215*155

Temperature range

(Low:A:+25ºC; B:0ºC;C:-20ºC; D:-40ºC;E:-60ºC;F:-70ºC) (High:+100ºC/+150ºC)

Humidity range

20%~98% R.H.(10%~98%R.H);(5%~98%R.His special optional condition)

Temp analytic accuracy/
uniformity

0.1ºC/±2.0ºC

Temperature Fluctuation

±0.5ºC

Humidity analytic accuracy/ Humidity control accuracy

±0.1%;±2.5%

Heating/cooling time

Heat up about 4.0°C/min ; Cooling about 1.0°C/min

Inner and outer materials

SUS#304 Stainless steel for inner chamber ; Carton Advanced cold plate nano paint for outer

Insulation materials

Resistant to high temp ,high density,formate chlorine,ethyl acetum foam insulation materials

Cooling system

Air cooling/single segment compressor(-40°C) ,air and water double segment compressor
(-50°C~-70°C)

Protection devices

Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch,
super humidity over-temperature protection switch, fuse, failure warning system

Parts

Watching window , 50mm testing hole , PL internal bulbs , Wet and dry bulb gauze , partition plate , castorx4,Foot Cupx4

Compressor

Original France "Tecumseh" brand

Controller

TATO Taiwan

Power

AC220V 50/60Hz & 1 , AC380V 50/60Hz 3

weight (kg)

150

220

270

320

450

580
