Measurement Range

-2000.0 mV to +2000.0 mV;-20.000 to +20.000 pH;0.05 - 100 mg KOH per gram

Measurement Resolution (mV)

Resolution: 0.1 mV; Accuracy: 0.1 mV ± 0.03%

Measurement Resolution (KOH)

0.02 mg of KOH per gram

pH Measurement

Resolution: 0.001 pH; Accuracy: 0.003 pH

Titration Volume Accuracy

0.001 mL

Measurement Mode

- MEAS: Measurement of pH/mV/T

- CAL: pH calibration (multiple points)

- SET: Sets the end-point mode

- MET: Equal volume titration

- DET: Dynamic Titration

Titration Mode

Acid-base titration, redox titration, precipitation titration, complexation titration, non-aqueous titration

Titration Cup Capacity

250mL

Temperature Measurement Range

-5 to 120 degrees Celsius

Temperature Measurement Accuracy

±0.1℃

Communication Methods

2 USB ports, 232 serial ports, Ethernet

Filling Unit

Built-in liquid filling unit

Simultaneous Liquid Addition Module Unit

(Standard configuration) Includes 2 sets of built-in titration and liquid addition channels

Number of Expandable Liquid Addition Channels

8 channels

Titration Tube Specifications

1ml, 5ml, 10ml, 25ml, 50ml (10ml is the standard size)

Resolution of the Burette

1/48,000

Time for Filling the Burette with Liquid

10 seconds (100% liquid filling speed)

Control Unit

PC with software (computer provided separately)

Automatic Sampler

Can be used in conjunction with the GT robot injection system for the analysis of large quantities of samples

Self-Check Function

Automatically checks the instrument status upon startup

Calibration Function

Yes

Apply Editing Function

Yes

Storage Space

More than 300G

Default Method Storage

Greater than 300G (Note: Assumed to be "Default method storage space" based on context)

Compliance & Management Functions

Compliant with FDA, GMP, and GLP;Equipped with audit tracking, hierarchical management, and electronic signature

Pipeline

PTFE titration tube (corrosion-resistant)

Stirring Method

Top-mounted spiral stirrer or magnetic stirrer

PTFE Valve

Imported corrosion-resistant rotary valve

Micro-Detection Electrode

Imported

Micro-Volume Infusion Pump

Imported
