MTN6725-0005S KNX DALI Broadcast Master Gateway
Advanced 4-channel KNX DALI broadcast master gateway supporting up to 32 ECGs per channel with comprehensive lighting control capabilities for commercial and industrial applications.
Technical Specifications
Model MTN6725-0005S
Type 4-channel KNX DALI Broadcast Master Gateway
Channels 4 independent DALI channels (electrically isolated into 2 groups)
Capacity Up to 32 ECGs per channel (maximum 128 total)
Compatibility DALI1 (IEC 62386-102 ed1) & DALI2 (IEC 62386-102 ed2)
Power Supply KNX Bus, DC 24 V (SELV)
Power Consumption Approximately 6.5 mA
KNX Support KNX TP1-256, KNX Data Secure
Installation DIN rail TH35 (EN 60715)
Insulation Protective separation between KNX bus and DALI power supplies
Core Functions
  • Converts KNX switching, dimming, and color commands to DALI broadcast telegrams
  • Supports DT8 colored light control (RGB, HSV, RGBW, color temperature)
  • Automatic "Dimm-To-Cold" color temperature adjustment based on light level
  • Integrated operating hours counter with individual fault detection per channel
  • Scene module supporting up to 16 scenes (assignable to KNX scenes 1-64)
  • Energy-saving function switches off ECG power when lights are off
  • Manual operation via on-device buttons with status/error LED diagnostics
  • Supports extension with up to 2 devices (DALI: MTN6825-0005 / Switch: MTN6805-0008)
Application Scenarios
  • Large-scale commercial lighting automation for offices, hotels, and retail spaces
  • Multi-zone DALI lighting systems requiring broadcast control
  • Projects requiring KNX Secure for enhanced security protection
  • New construction and retrofits with mixed DALI1/DALI2 ballasts
  • Energy-efficient lighting management with automatic scheduling and fault monitoring
Key Advantages
  • 4-channel isolated design for flexible zoning and system scalability
  • No DALI commissioning required, simplifying installation process
  • Comprehensive color light control (DT8) for modern LED fixtures
  • KNX Secure compatibility protects against unauthorized access
  • Integrated power supply for ECGs eliminates need for external DALI PSUs
  • Compact DIN-rail form factor for easy cabinet integration
