Specifications
Brand Name :
KSPOWER
Model Number :
KS-12240a-M#
Certification :
UL FCC CE ROHS SAA CLASS 2 CLASS P etc.
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
$60.52-65.8/pieces
Payment Terms :
T/T
Supply Ability :
300000pcs/month
Delivery Time :
20-25 days
Packaging Details :
Small box and Cartons
Warranty(Year) :
5-Year
Lighting solutions service :
Lighting and circuitry design
Output Power :
240W
Output Type :
PWM or DC
Input Voltage :
100-277V
Output Frequency :
50/60Hz
Application :
LED Strip Light,Pendants, Linears,Cove Lights
Warranty :
5 years
Protection :
OCP, OVP, SCP, OTP
IP Rate :
IP65
Efficiency :
≥90%
Output :
12V24V36V48V
Description

12V 4x60W(240W) 5 In 1 Dimming Class 2 LED Lights Driver

The KSPOWER’s MVP Series 5-in-1 dimmable LED power supply features a universal 100–277VAC input and multiple constant-voltage outputs 12V. This 60W per-channel, 4-way driver provides smooth compatibility with MLV, ELV, and phase-cut dimmers. The patented aluminum housing enhances durability, while NEMA 3R protection ensures reliable operation in outdoor environments. Certified to UL cUL Class 2 and CE, this LED transformer offers superior energy efficiency and long-term reliability backed by a 5-year warranty.
240W 5 In 1 Dimming IP65 Rated LED Lights Driver and Dimmable LED Power Supply
Key Features
  • PWM or Voltage Reduction output Selectable
  • 3-Ways Universal Dimming Functions optional:
    • 5 in 1 dimming: TRIAC, ELV, MLV, 0-10V, 1-10V, 10V PWM and potentiometer dimming
    • Triac dimming: TRIAC/phase, ELV, MLV dimming
    • 4 in 1 dimming: 0-10V, 1-10V, 10V PWM and potentiometer
    • Non-dimming
  • Super compact Aluminum case
  • UL/cUL CE Class 2 CLASS P FCC RoHS LPS certified
  • NEMA 3R rated for Indoor or Outdoor Use
  • Switch to dual-color temperature LED Strips with 100%-0.01% dimming flicker-free
  • Auto-Reset Protection for input/output overvoltage protection, input/output overcurrent protection, over temperature protection, over power protection and short circuit protection
Specifications
ModelKS-12240a-M#
Output Voltage12V
Rated current×Channel5.0A×4
Rated Power240W
Ripple&Noise(Max)200mVp-p
Voltage Accuracy±2.0%
Linear Adjustment Rate±0.5%
Load Adjustment Rate±0.5%
Start Rise Time1000ms, 100ms/230VAC, 1100ms, 100ms/115VAC
Hold Time10ms/115VAC, 230VAC
Input Voltage Range100 ~ 277VAC
Frequency Range47 ~ 63Hz
Power FactorPF≧0.98/115VAC, PF≧0.95/230VAC, PF≧0.9/277VAC, Full load
Total Harmonic DistortionTHD< 20% (@ load ≧50%/115VC,230VAC; @ load ≧75%/277VAC)
Efficiency Vin:115VAC≧91.56%
Efficiency Vin:230VAC≧94.63%
AC Current3.0A
Inrush CurrentCold start 75A(width=350us measured at 50% l peak)/230Vac
Leakage Current< 1 mA
No Load/Standby Power Consumption< 4.0W
Over Current Protection95~110% Constant current limit, load abnormal condition can be removed after automatic recovery
Short Circuit ProtectionBurp mode, load abnormal conditions can be removed after automatic recovery
Over Voltage Protection13~16V
Over Temperature ProtectionTurn off the output voltage, restart and resume
Working TemperatureT case=-40 ~ +50℃
Max Case TemperatureT case=+90℃
Working Humidity20 ~ 95% RH, non-condensing
Storage Temperature,Humidity-40 ~ +90℃, 10 ~ 95% RH
Temperature Coefficient±0.03%/℃ (0 ~60℃)
Vibration10~500Hz, 5G 12min./1 cycle, period for 72 min. each along X,Y,Z axes
Safety StandardUL8750 & UL1310
Withstand VoltageI/P-O/P.1.88KVac
Isolation ResistanceI/P-O/P.100MΩ/500VDC/25℃/70%RH
EMC EMISSIONConfirms to FCC
240W 5 In 1 Dimming IP65 Rated LED Lights Driver and Dimmable LED Power Supply
Technical Specifications
Dimming StyleSeriesPowerInput voltageOutput voltage&
Output current		Size
12V24V36V48V
5 in 1 dimmingMVP100W100~277V
50/60Hz		4.16A*22.08A*21.38A*21.04A*2199*103*40mm
180W100~277V
50/60Hz		5A*3///216*113*40mm
192W100~277V
50/60Hz		/4A*22.67A*22A*2216*113*40mm
240W100~277V
50/60Hz		5A*4///248*123*40mm
288W100~277V
50/60Hz		/4A*32.67A*32A*3248*123*40mm
300W100~277V
50/60Hz		5A*5///248*123*40mm
384W100~277V
50/60Hz		/4A*42.67A*42A*4248*123*40mm

Custom labeling, packaging, and cases are available. We provide OEM and ODM services.
