RF/Microwave PCB with Low Loss Materials for 5G Base Stations and Radar Systems
RF/Microwave PCB with Low Loss Materials for 5G Base Stations and Radar Systems
Specifications
Certification :
ISO9001
Layer Count :
1 – 10 layers
Payment Terms :
L/C,D/A,D/P,T/T
Surface Finish Options :
HASL, ENIG, OSP, Immersion Tin, Immersion Silver
Brand Name :
Jiaqing Circuit
Price :
negotiate
Delivery Time :
15-30 Days
Operating Temperature :
-20°C to +130°C
Thermal Conductivity :
Enhanced via copper mass
Place of Origin :
China
Description

This RF/Microwave PCB is engineered for high-frequency applications requiring superior signal integrity and low dielectric loss. Utilizing advanced materials including Rogers, Taconic, and Isola substrates, these boards maintain stable dielectric properties across frequency and temperature ranges. Ideal for 5G infrastructure, radar systems, and satellite communications, the boards feature controlled impedance (±5%), fine-line geometries, and specialized surface finishes (ENIG or Immersion Silver). Low loss tangent (0.001-0.003) minimizes signal attenuation, enabling high-frequency performance up to 100GHz.


Applications & Advantages by Category

5G Base Stations – Stable dielectric properties and low dissipation factor ensure minimal signal loss in millimeter-wave applications.

Radar Systems – Controlled impedance enables accurate signal propagation in phased-array and automotive radar modules.

Satellite Communications – Low loss and stable performance across temperature ranges support reliable communication links.

Microwave Assemblies – Superior signal integrity for high-frequency test equipment and measurement systems.

Telecommunications – High-speed digital and RF mixed-signal designs benefit from the low-loss characteristics.
