Aluminum Base PCB for LED Lighting and Consumer Power Applications
Aluminum Base PCB for LED Lighting and Consumer Power Applications
Specifications
Payment Terms :
L/C,D/A,D/P,T/T
Layer Count :
1 – 10 layers
Surface Finish Options :
HASL, ENIG, OSP, Immersion Tin, Immersion Silver
Brand Name :
Jiaqing Circuit
Thermal Conductivity :
Enhanced via copper mass
Operating Temperature :
-20°C to +130°C
Place of Origin :
China
Price :
negotiate
Certification :
ISO9001
Delivery Time :
15-30 Days
Description

This Aluminum Base PCB (Aluminum Core PCB) combines a thermally conductive aluminum substrate with standard circuit fabrication processes. The aluminum base provides effective heat dissipation at a more accessible price point than copper-based designs. Available in single-sided and double-sided configurations, this board is the industry standard for consumer LED lighting, power supplies, and automotive electronics. The board’s dielectric layer provides electrical isolation while maintaining excellent heat transfer from components to the aluminum base.

Applications & Advantages by Category
  • LED Lighting – Effective heat dissipation for high-brightness LEDs, including downlights, streetlights, and horticultural lighting.
  • Power Supplies – Heat spreading for power semiconductors in consumer and industrial power supplies.
  • Automotive Electronics – Lightweight thermal management for LED lighting and sensor modules.
  • Consumer Electronics – Cost-effective thermal solution for power amplifiers and display backlighting.
