PC32TB-PLUG PC Series Russian Standard Threaded Circular Connector 32 Pin Plug Connector
PC32TB-PLUG PC Series Russian Standard Threaded Circular Connector 32 Pin Plug Connector
PC32TB-PLUG PC Series Russian Standard Threaded Circular Connector 32 Pin Plug Connector
PC32TB-PLUG PC Series Russian Standard Threaded Circular Connector 32 Pin Plug Connector
PC32TB-PLUG PC Series Russian Standard Threaded Circular Connector 32 Pin Plug Connector
PC32TB-PLUG PC Series Russian Standard Threaded Circular Connector 32 Pin Plug Connector
Specifications
Insulation resistance :
≥ 1000 MΩ
PCMleakage rate :
Under a standard atmospheric pressure difference, the leakage rate isless than 0.1 Pa·cm²/s
Packaging Details :
standard export package
Place of Origin :
China
Payment Terms :
L/C,T/T,Western Union
Ambienttemperature :
-60℃ to +85℃
MOQ :
10PCS
Service life :
15 years
Delivery Time :
2--9 weeks
Brand Name :
Jovelix
Supply Ability :
100,000pcs per month
Technical specification :
3E0 204 062JT
Contact resistance :
≤5 mΩ
Model Number :
PC32TB-PLUG
Price :
10＄--150＄
Operating voltage :
200V
Certification :
AS9001
Vibration acceleration :
5-2500 Hz,PC 15g,PCΓ 18g
Dielectric strength :
1000V
lmpact acceleration :
PCrepeated 50g;PCΓ repeated 100g
Mating cycles :
250 cycles
Description

PC series ultra-small circular electrical connectors are designed for circuit connection in radio equipment, electrical devices, instruments, and other electronic systems requiring compact and reliable interconnection. This series adopts a threaded coupling structure, allowing a cable plug to be securely connected with a receptacle installed on the equipment panel. The threaded locking design helps ensure stable mating performance and reduces the risk of accidental loosening during use.

In addition to cable-to-equipment connection, PC ultra-small connectors can also be used for direct equipment-to-equipment interconnection. By mounting a plug and a receptacle on two separate devices, the two units can be connected directly without additional transition components, making the system layout more compact and convenient.

The PC series ultra-small circular connector is available in both sealed and unsealed versions to meet different installation and environmental requirements. Plugs and receptacles can be supplied with or without backshell assemblies according to cable routing and protection needs. In this configuration, the receptacle is fitted with pin contacts, while the mating plug is fitted with socket contacts to ensure proper electrical connection and reliable mating.

PC32TB-PLUG PC Series Russian Standard Threaded Circular Connector 32 Pin Plug Connector

Contacts Layout (viewed from the female side) Φ=1mm

PC32TB-PLUG PC Series Russian Standard Threaded Circular Connector 32 Pin Plug Connector

Appearance and installation dimensions (mm)
Contact num D D1 d1 A B b
PC-4 M10*0.75 M10*0.75 2.2 11.8±0.1 16.5 1.4
PC-7 M12*0.75 M12*0.75 2.2 13.2±0.1 18 1.4
PC-10 M14*0.75 M14*0.75 2.2 15±0.1 20 1.4
PC-19 M18*0.75 M18*1 2.2 18±0.1 24 1.4
PC-32 M22*0.75 M22*1 2.7 21.5±0.1 28 1.8
PC-50 M27*0.75 M27*1 3.2 26±0.1 33 2.0
