720×1440 5.5-Inch TFT LCD Module, PL7703N-G5-DP 5.5-Inch TFT LCD Module, MIPI TFT Display 5.5-Inch

5.5-Inch TFT LCD Portrait HD 720×1440 Dots, PL7703N-G5-DP MIPI Interface, IPS Free Viewing Angles with Custom CTP

5.5-Inch TFT LCD with CTP, HD 720×1440 TFT CTP Display

Description

The Jingtai Liquid Crystal Display Technology JT-5.5IPSHD+ is a 5.5-inch TFT LCD module with a resolution of 720 × 1440 pixels. This module integrates the PL7703N-G5-DP controller and driver IC, supports a MIPI interface, and operates at a supply voltage (Vdd) ranging from 2.6V to 3.3V, with a typical value of 2.8V. It features IPS technology with wide viewing angles of 80°/80°/80°/80° (left/right/up/down).

The JT-5.5IPSHD+ is a portrait-mode TFT LCD module with a brightness of 250 nits. It is available with capacitive touch screens. The module operates in temperatures from -20℃ to +70℃ and can be stored in temperatures from -30℃ to +60℃. This 5.5-inch TFT LCD is widely used in industrial devices, scanners, home automation, access control systems, monitoring equipment, analyzers, security systems, garden irrigation systems, PDA, POS and more.

Product Advantages

1. Excellent display performance in background color, luminance, viewing angle, and intensity

2. Wide operating temperature range (-20℃ to +70℃) for industrial applications

3. Stable supply chain with continuous mass production for over 5 years; no EOL concerns

4. Flexible configuration with or without resistive touch screen; customized capacitive touch panel (CTP) options available

5. Customizable FPC with various interfaces, pin counts, and pin assignments

6. Cost-effective solution within the LCD industry

7. Easy to install and maintain

Industrial TFT Display 5.5 Inch, 5.5 Inch HD+ Industrial Capacitive Touch LCD Drawing
