8.86 Inch TFT LCD Display Module For PDA POS Terminal With MIPI Interface
8.86 Inch TFT LCD Display Module For PDA POS Terminal With MIPI Interface
Specifications
Price :
1-20
Display Mode :
IPS
Touch Screen :
CTP
Luminance :
500 cd/m²(Typ)
Delivery Time :
1-5 weeks
Interface Definition :
MIPI
Viewing Angle :
85/85/85/85
Place of Origin :
Shenzhen/China
Model Number :
JT-8.68IPSHD+INCELL
Key Words :
8.68 Inch IPS HD
CTP Interface :
12C/USB
Payment Terms :
T/T,Western Union,L/C,MoneyGram,D/A,D/P
Supply Ability :
2000K Pcs Per Month
Packaging Details :
Standard Exportation Package
Certification :
ISO9001 / ISO14000
Brand Name :
Jingtai
Resolution :
800*1340
MOQ :
5pcs
Description

8.86 Inch TFT LCD Display Module For PDA POS Terminal With MIPI Interface

Product Introduction

This 8.86 inch TFT LCD display module is designed for PDA POS terminals, handheld display devices, embedded products, and smart commercial equipment. The module features an 800×1340 resolution and supports MIPI interface connection for stable display transmission in compact electronic systems.

The TFT LCD module adopts Normally Black display mode and wide viewing angles of 85/85/85/85, helping provide stable screen visibility for PDA terminal and POS display applications. With 500 cd/m² typical brightness and 60% NTSC color performance, the display module is suitable for indoor smart terminal equipment and portable display systems.


Stable TFT LCD Display Performance

This TFT LCD display module is suitable for embedded display applications requiring compact structure and reliable display performance. The slim module outline size of 117.64×198.59×2.32mm helps support lightweight handheld device designs and portable terminal integration.

The MIPI interface can provide stable signal transmission for PDA POS display systems, handheld terminals, portable testing equipment, and embedded products. The display module supports long working time applications requiring stable TFT LCD display output.


Application Areas

This 8.86 inch TFT LCD module can be used in:

* PDA POS terminals
* Handheld payment devices
* Portable smart terminals
* Embedded display products
* Industrial handheld equipment
* Information display systems
* Smart commercial devices

The module is suitable for embedded TFT LCD display projects requiring stable image display and compact installation structure.


Environmental Reliability

The operating temperature range is -20℃ to +70℃, and the storage temperature range is -30℃ to +80℃. The TFT LCD display module can support different commercial and industrial working environments.

Customized services are available according to customer requirements, including touch panel integration, brightness adjustment, interface customization, and structural modification for different embedded display applications.


Product Specifications

Number Of Pixels

800*1340pixels

Active Area

113.4*189.342mm

Module Outline

117.64*198.59*2.32mm

Aspect Ratio

16:10

Display Model

Normally Black

Viewing Angle(CR>10)

85/85/85/85

NTSC

60%TYP

LCM Brightness

500 cd/m²(Typ)

Interface

MIPI

Operating Temperature

-20~+70℃

Storage Temperature

-30~+80℃
