CAT7A SFTP Cable 1000MHz Solid Copper for Industrial Network & Data Center
CAT7A SFTP Cable 1000MHz Solid Copper for Industrial Network & Data Center
CAT7A SFTP Cable 1000MHz Solid Copper for Industrial Network & Data Center
CAT7A SFTP Cable 1000MHz Solid Copper for Industrial Network & Data Center
CAT7A SFTP Cable 1000MHz Solid Copper for Industrial Network & Data Center
CAT7A SFTP Cable 1000MHz Solid Copper for Industrial Network & Data Center
Specifications
Brand Name :
ITI -LINK
Model Number :
ITI-CTSF7A-018
Certification :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Place of Origin :
Shenzhen
MOQ :
1000pcs
Price :
50$-100$
Payment Terms :
T/T
Supply Ability :
2000pcs/day
Delivery Time :
15-45 Days
Packaging Details :
Outer box size (for packing): 64X32X23CM
Jacket Material :
PVC
Transmission Speed :
10Gbps
Jacket Color :
Orange
Length :
50m
Conductor Material :
Copper
Conductor Size :
23 AWG
Frequency :
1000 MHz
Cable Type :
SFTP (Shielded Foiled Twisted Pair)
Description
CAT7A SFTP Cable 1000MHz Solid Copper for Industrial Network & Data Center
The ITI-LINK ITI-CTSF7A-018 CAT7A SFTP Cable is a professional Shielded LAN Cable engineered for high-speed industrial networks and modern data centers. Built with 23AWG solid copper conductors and SFTP double shielding, this CAT7A Industrial Network Cable supports 1000MHz bandwidth and 10Gbps data transmission. The durable PVC / LSZH orange jacket offers excellent protection against abrasion, interference, and harsh environments.
Product Features
  • Premium Construction: 23AWG solid copper conductors with advanced SFTP shielding
  • High Performance: Supports 10Gbps data transmission and 1000MHz bandwidth
  • Superior Shielding: Foil and braided shielding effectively blocks EMI and RFI interference
  • Durable Materials: Four twisted pairs of solid oxygen-free copper with PVC/LSZH jacket
  • Industrial Grade: Designed for harsh environments and long-term reliability
Construction Specifications
Component Specification
Conductor 23AWG Bare Solid Copper (elongation: 19-24%)
Insulation PE Skin-Foam-Skin, OD: 1.45 ±0.01 mm
Pair Colors 1p: Blue stripe + white + blue stripe & blue
2p: Orange stripe + white + orange stripe & orange
3p: Green stripe + white + green stripe & green
4p: Brown stripe + white + brown stripe & brown
Pair Twist Lay 1p: 19.0 mm | 2p: 23.5 mm | 3p: 21.5 mm | 4p: 25.0 mm
Pair Shield Polyester/Aluminium (PET/ALU), Coverage: ≥ 115%
Braid ɸ 0.12mm Aluminum-magnesium braided, Coverage: ≥ 40%
Jacket PVC, 50P, -20~75℃, OD: 8.5 ± 0.2 mm
Electrical Properties
Parameter Value
Conductor Resistance at 20°C ≤ 9.5 Ω / 100m
Resistance unbalance within a pair ≤ 2%
Insulation Resistance at 20°C >1500 MΩ / 100m
Mutual capacitance 5600 pF / 100m MAX
Characteristic impedance at 100MHz 100 ± 15 Ω
Transmission Performance (CAT7A Standards)
Frequency (MHz) Attenuation Max (dB/100m) Return Loss Min (dB) NEXT Min (dB)
100 18.5 20.1 75.4
250 29.7 17.3 69.4
500 42.8 17.3 64.9
1000 61.9 15.1 60.4
Applications
  • Industrial Automation Systems: Connects PLC controllers, robotic production lines, sensors, and monitoring systems with stable 10Gbps connectivity
  • Data Center Infrastructure: Ideal for high-density server environments requiring high-bandwidth and low-latency transmission
  • 5G Base Stations & Telecommunications: Provides reliable shielded network connectivity for 5G communication equipment
  • Energy & Power Industry: Suitable for power plants, substations, and energy monitoring systems where EMI-resistant cables are essential
  • Enterprise & Commercial Networks: Supports high-speed LAN connectivity for office buildings and enterprise IT infrastructure
