Specifications
Brand Name :
ISUZU
Model Number :
CL5051GKZY1
Certification :
CGC，ISO9001:2015，TUV SUD，PV，CNAS
Place of Origin :
China
MOQ :
1 UNIT
Price :
USD 33600- USD 49200/ UNIT
Delivery Time :
45-60 work days
Fuel :
Diesel
Transmission Type :
Manual
Drive Wheel :
4x2
Condition :
New
Supporting Leg :
Hydraulic
Working Height :
14m
Bucket Size :
1200*600*1100
Warrany :
1 Year
Bucket Loading :
200kg
Boom Type :
Telescopic
Color :
Custimized
Product :
Aerial Lift Bucket Trucks
Transport Package :
Nude, by Roro Ship, Bulk Ship or Frame Container
Specification :
5990*1980*2900mm
HS Code :
8705909990
Type :
Telescopic
Description

ISUZU KV100 27M Telescopic Boom Aerial Platform Lift Truck Aerial Work Vehicle

Product Description

-About Aerial Platform Truck:

Our unique design operation system of three-section telescopic boom could help the worker stable operation in the air.
The main purposes are: maintaining, installing, cleaning, camera shooting, ship bulding, chemical industry, electric power, pruning and streetlight changing etc. in the air from 8m to 24m height.

-Characteristics:

1. The boom is made of high-strength steel plate HQ60/5mm welded and formed, and the outriggers are made of low-alloy Q345 profile, with no welds around, beautiful appearance, strong force and high strength;
2. The cylinder drive chain drives the telescopic arm to expand and contract synchronously, which is stable and reliable;
3. H-shaped outriggers have good stability, the outriggers can be operated at the same time or individually, and the operation is flexible and can adapt to a variety of working conditions;
4. The turntable rotates in two directions at 360°, and adopts an advanced worm and worm integrated closed reduction mechanism; (with self-lubricating and self-locking functions)
5. Automatic control by controller, with display screen, set protection mode to limit amplitude, safe and reliable;
6. Two-position operation of getting off the car and the hanging basket, electro-hydraulic proportional speed regulation;
7. Getting off and getting on is interlocked, the operation is safe and reliable;
8. The hanging basket adopts advanced static hydraulic automatic leveling, which is more stable and reliable;
9. There are engine start and stop switches for getting off the car and the hanging basket, which is easy to operate and save fuel;

KV100 27M ISUZU Aerial Platform Truck 116HP ISO9000 CCC Certification

KV100 27M ISUZU Aerial Platform Truck 116HP ISO9000 CCC Certification

KV100 27M ISUZU Aerial Platform Truck 116HP ISO9000 CCC Certification

Product Parameters

Vehicle Description
Vehicle model Platform Truck Overall dimensions (mm) Approx. 6000*2050*3050
GVW (kg) Approx.5555 Operational height (m) 27
Mass in working order (kg) Approx.4995 Max. Speed (km/h) 90
Chassis Description
Chassis brand ISUZU
Cab Double row cab with A/C
Wheel base (mm) 3360
Number of axles 2
Axle Front axle 2000
Rear axle 3000
Traction system

4x2
Operation control system Power steering
Braking system Oil brake
Transmission 5-speed MSB
Tire specification 7.00-15
Tire quantity

6+1
Engine Description
Engine manufacture ISUZU Engines
Engine model 4JB1CN
Type Water-cooled four-stroke, supercharged inter-cooling
Emission standard Euro 4
Up-parts Description
Working condition
Max. working height (m) 27
Working radius at Max. height (m)

24
Max. working radius (m)

13
Working height at Max. radius (m)

6
Control mode

1.Bucket control

2.Manual operation

Bucket
Rated loading (kg)

250
Size (mm)

1400*700*1100
Material Stainless steel
Adjusting balance mode Hydrostatic Leveling System
Safety belt 1 set

Boom
Type Telescopic type
Section

3
Rotation Angle

360
Thickness of boom plate (mm)

4
Max. rising angle of boom -20º ~ +75°

Outrigger
Type Front V type / Rear H type
Vertical Breadth (mm)

4000
Horizontal Breadth (mm)

4000
Number

4
Adjustment Adjusted separately
Supporting leg Control mode Manual hydraulic operation
Hydraulic lock Two-way hydraulic lock for four legs
Strobe light on rear landing legs Two yellow lights
Main body structure
Material High quality carbon steel and profiles, with slip-proof decorative steel plates
Tool box Mould stamping door with stainless steel door lock
Fencing Stainless steel tube
Steps With steps on drivers’ side
Guard railing High quality cold bending carbon steel profile; High strength
Wheel casing Injection mold molding, beautiful, high strength
Security configuration
Automatic interlock device for different operating position Prevent the risk of misoperation
Hand-operated emergency pump When the engine and the main pump failure, through the emergency system to send the worker back to the ground and the vehicle back to the running state
Emergency stop device for working platform Used for emergency stop operation and restricted boom operation
Automatically limit work range When the working range reaches the specified value, the dangerous direction is automatically restricted.
Leakage protection device Equipped with leakage protector to ensure the safety of power supply and power tools

Product Details
