Vehicle Description | |||||
Vehicle model | Platform Truck | Overall dimensions(mm) | 7385×1980×3140 | ||
GVW (kg) | Appro×7000 | Operational height (m) | 18 | ||
Mass in working order (kg) | Appro×6165 | Max. Speed (km/h) | 95 | ||
Chassis Description | |||||
Cab | Double row cab with A/C | ||||
Wheel base (mm) | 3815 | ||||
Number of axles | 2 | ||||
Axle | Front axle | 2000 | |||
Rear axle | 4800 | ||||
Traction system | 4x2 | ||||
Operation control system | Power steering | ||||
Braking system | Oil brake | ||||
Transmission | 5-speed MSB | ||||
Tire specification | 7.00R16 | ||||
Engine Description | |||||
Engine manufacture | ISUZU Engines | ||||
Engine model | 4KH1CN5HD | ||||
Emission standard | Euro 5 | ||||
Up-parts Description | |||||
Bucket | |||||
Max. working highe (m) | 16m | ||||
Max. working radius (m) | 8 | ||||
Rated loading (kg) | 200 | ||||
Size (mm) | 1100*600*1200 | ||||
Type | Insulation type | ||||
Boom | |||||
Type | Three section , Telescopic | ||||
Rotation Angle | 360 | ||||
Rotation speed (r/min) | 0-2 | ||||
Boom Control mode | 1.Bucket control 2.Manual operation | ||||
Outrigger | |||||
Type | H | ||||
Vertical Breadth (mm) | 4000 | ||||
Horizontal Breadth (mm) | 4000 | ||||
Adjustment | Adjusted separately |
