Specifications
Chassis Material :
All Aluminum
Display Chip :
Intel UHD Graphics 630/750
Expansion Slots :
Mini PCIe, MSATA
Input Voltage :
DC 12～24V
Memory Slots :
2 * DDR4 SODIMM
Network Ports :
3*Intel 2.5G LAN
Certification :
CE/CCC/FCC Class A/RoHS
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
10000 Set
Delivery Time :
7-10 work days
Packaging Details :
Standard carton package : carton+ plastic bag+ foam+ honeycomb paperboard+ pack thread.
Dimensions :
225 * 240 * 83 mm
USB Ports :
6*USB3.0
Working Humidity :
5% ～ 95%
Hard Drive Capacity :
256GB
Max Memory :
64GB
Weight :
2.78kg
Display Ports :
1*HDMI, 1*DP
Working Temperature :
0℃ ～ +50℃
Brand Name :
MTHGH
Model Number :
IEXP-502
Place of Origin :
China
Hard Drive Type :
SSD
Processor :
I3/i5/i7
Storage Support :
2*2.5inch HDD
BIOS :
AMI UEFI BIOS
Description
IEXP-502 Industrial Mini PC With Mini PCIe Expansion Slot Windows/Linux Operating System
Industrial Mini PC IEXP-502

Intel® Core™ i3/i5/i7 10th /11th processor industrial computer

Key Features
  • High quality aluminum alloy + sheet metal structure
  • Support Core™ i3/i5/i7 10th /11th processor
  • Support 2*DDR4 3200 SODIMM memory slot, Max. 64GB
  • Support 3*Intel 2.5G Lan
  • Support 2*M.2 slot, support the 4G/5G function
  • Support 6*COM (COM1,2 can be option RS232/485 mode)
  • Support DC 12～24V wide voltage
  • Compatible operating systems:
IEXP-502 Industrial Mini PC with Mini PCIe Expansion Slot and Intel Core i3/i5/i7 10th/11th Processor in All Aluminum Chassis IEXP-502 Industrial Mini PC with Mini PCIe Expansion Slot and Intel Core i3/i5/i7 10th/11th Processor in All Aluminum Chassis IEXP-502 Industrial Mini PC with Mini PCIe Expansion Slot and Intel Core i3/i5/i7 10th/11th Processor in All Aluminum Chassis
IEXP-502 Industrial Mini PC with Mini PCIe Expansion Slot and Intel Core i3/i5/i7 10th/11th Processor in All Aluminum Chassis
Product Specifications
ModelIEXP-502
ColorGrey + white (Colors can be customized)
MaterialHigh quality aluminum alloy (hard anodized surface) + sheet metal structure (spray paint)
ProcessorIntel Core i3 10305T (quad core eight threads, base 3.0 GHz, burst 4.0 GHz)
Intel Core i5 10500T (six core twelve threads, base 2.3 GHz, burst 3.8 GHz, 12MB cache)
Intel Core i7 10700T (eight core sixteen threads, base 2.0 GHz, burst 4.5 GHz, 16MB cache)
MemorySupport 2 * DDR4 2666/3200MHz SODIMM memory slot, Max. 64GB
BIOSAMI UEFI BIOS
Display chipIntegrated Intel UHD Graphics 630 / Intel UHD Graphics 750
Display port1*HDMI, 1*DP (Supports synchronous and asynchronous dual display)
Front I/O1*4 Pin Phoenix terminal, 1*HDMI, 1*DP, 6*COM (COM1,COM2 can be option RS232/RS485), 6*USB3.0, 3*Intel 2.5G network port, 1*Mic, 2*Audio, 1*Power Button
ExpansionSupport 1*M.2 M-Key 2280 slot (support SATA/PCIE X4 NVME signal)
Support 1*MINI PCIE slot (support WIFI/BT)
Support 2*M.2 B-key slot 3042/3052 (support 4G/5G), with SIM card slot
Expansion (the standard isn't included): 4*USB2.0, 16 bits GPIO
Network3*Intel i225-V 2.5G LAN port
StorageSupport 1*M-Key 2280 slot (support SATA/PCIE X4 NVME), 2*2.5inch HDD
Input voltageSupport 4 Pin Phoenix terminal, DC 12～24V wide-voltage input
Other functionsPower-on, timed startup, network wake up, PXE startup, watchdog (level 0 to 255), TPM2.0
Working temp.0℃ ～ +50℃ (business HDD), -20℃ ～ +60℃ (industrial SSD), Surface air flow
Working humidity5% ～ 95% Non-condensing state
CertificationCE, CCC, FCC Class A, RoHS
Dimension225 * 240 * 83 mm
Weight2.78kg (isn't included the wall mount)
InstallationWall mount (standard), DIN rail mount (Optional), desktop (Default)
ApplicationIndustrial automation, medical, logistics, transportation, warehousing, e-education, etc.
Package Contents
NameQuantitySpecification
Power adapter112V 10A
Power cable1CN, US, EU, UK plug, etc
Certification1Yanling/Neutral
Warranty card1adapter
Wall mount2Standard
Available Configurations
ConfigurationModelProcessorI/O
Config 1IEXP-502Intel Core i3 10305TStandard I/O
Config 2IEXP-502Intel Core i5-10500TStandard I/O
Config 3IEXP-502Intel Core i7 10700TStandard I/O
Config 4IEXP-502Intel Core i5-11600TStandard I/O
Config 5IEXP-502Intel Core i7-11700TStandard I/O
