Key Functions

1. 24-bit High-Resolution Analog-to-Digital ConversionDelivers 24-bit no-missing-code performance, supporting a maximum data rate of 2 kSPS (kilosamples per second). It ensures high-precision digitization of analog signals, ideal for applications requiring fine-grained measurement of physical quantities.
2. Integrated Programmable Gain Amplifier (PGA)Features a built-in PGA with selectable gain levels from 1 to 128, enabling amplification of weak input signals (e.g., from sensors) while suppressing noise. This eliminates the need for external amplification circuits, reducing system complexity and cost.
3. Versatile Input MultiplexingEquips a flexible input multiplexer that supports 8 single-ended inputs or 4 differential inputs. It allows the device to interface with multiple sensors or signal sources sequentially, suitable for multi-channel data acquisition systems.
4. Low-Drift Voltage ReferenceIncorporates an on-chip low-temperature-drift voltage reference (typical drift of 5 ppm/°C), ensuring stable reference voltage supply across the operating temperature range of -40°C to +125°C, and enhancing long-term measurement accuracy.
5. Ultra-Low Power ConsumptionOperates at ultra-low quiescent current (as low as 600 nA in standby mode), making it well-suited for battery-powered, portable, or remote monitoring devices where power efficiency is critical.
6. Built-in Sensor Excitation CircuitsProvides integrated current excitation sources, which can directly power resistive sensors (e.g., thermistors, strain gauges, pressure sensors) without additional external driving circuits.

Typical Applications

1. Industrial Process Control
   • Precision measurement of temperature, pressure, flow rate, and level in industrial plants.
   • Data acquisition for process monitoring systems, ensuring reliable and accurate control of production lines.
2. Precision Sensor Interfaces
   • Interface with high-sensitivity sensors such as strain gauges, load cells, thermocouples, and RTDs (Resistance Temperature Detectors).
   • Signal conditioning and digitization for weighing scales, force measurement devices, and temperature calibration equipment.
3. Portable and Battery-Powered Instruments
   • Handheld test meters, portable data loggers, and field measurement devices requiring low power and high accuracy.
   • Remote environmental monitoring systems (e.g., soil moisture, air quality) deployed in off-grid locations.
4. Medical and Biomedical Devices
   • Precision signal acquisition for medical equipment such as patient monitors, blood glucose meters, and electrocardiogram (ECG) devices.
   • Sensor data digitization for wearable health monitoring devices, ensuring low power consumption and high measurement fidelity.
5. Energy Management Systems
   • Power consumption monitoring in smart grids, building automation systems, and energy-efficient appliances.
   • Current and voltage measurement in battery management systems (BMS) for electric vehicles and renewable energy systems.
