1. Core Functionality

• Reinforced Isolation Capability: Provides 5 kV RMS isolation voltage for 1 minute and 2.5 kV RMS continuous working isolation voltage, meeting IEC 61010-1, IEC 60747-5-5 and UL 1577 safety standards. It effectively isolates high-voltage transients, eliminates ground loop interference, and protects low-voltage control circuits from high-voltage side faults.
• Dual-Channel Configuration: Equipped with 2 independent isolation channels, supporting configurable unidirectional or bidirectional data transmission with CMOS/LVCMOS logic level compatibility. This flexible architecture adapts to diverse interface isolation requirements in compact system designs.
• High-Speed & Low-Latency Transmission: Delivers a maximum data rate of 100 Mbps with ultra-low propagation delay, ensuring real-time signal transmission for time-critical applications such as motor control and high-speed communication interfaces.
• Automotive-Grade Robustness: Operates stably over a wide temperature range of -40°C to +125°C, with excellent ESD protection (±15 kV HBM) and high electromagnetic interference (EMI) immunity. It maintains reliable performance under extreme conditions of vibration, humidity, and voltage fluctuation.
• Low Power Consumption: Features ultra-low quiescent current and a shutdown mode, minimizing power dissipation in battery-powered automotive subsystems and low-power industrial equipment.

2. Typical Applications

• Automotive Electronics
  • Electric vehicle (EV)/hybrid electric vehicle (HEV) battery management systems (BMS) for cell monitoring signal isolation
  • Automotive powertrain control modules (PCM) and transmission control units (TCU) for sensor/actuator signal isolation
  • Advanced driver assistance systems (ADAS) for radar/lidar sensor interface isolation
  • On-board charging (OBC) systems for high-voltage side signal isolation
• Industrial Automation
  • Programmable logic controller (PLC) digital I/O isolation modules
  • Servo motor and frequency converter control signal isolation
  • Industrial fieldbus (CAN FD, Modbus) communication interface isolation
  • High-voltage power supply monitoring circuit isolation
• High-Reliability Instrumentation
  • Medical diagnostic equipment for patient-side signal isolation
  • Test and measurement instruments for input/output channel isolation
  • Aerospace and defense systems for low-power isolated data links

Key Specifications Summary

• Isolation Voltage: 5 kV RMS (1 min withstand), 2.5 kV RMS (working)
• Number of Channels: 2 (dual-channel)
• Maximum Data Rate: 100 Mbps
• Operating Temperature Range: -40°C to +125°C
• Input/Output Compatibility: CMOS/LVCMOS logic levels
• Compliance Standards: IEC 61010-1, IEC 60747-5-5, UL 1577, AEC-Q100 Grade 1
• Package: 8-Pin Wide Body Small Outline Integrated Circuit (SOIC-W)
• ESD Protection: ±15 kV (HBM)
