1. Core Functionality

• Bidirectional Surge Protection: Provides symmetrical clamping capability for both positive and negative transient voltages, effectively suppressing ESD, electrical fast transients (EFT), and lightning-induced surges.
• Low Clamping Voltage: Delivers a low maximum clamping voltage under surge conditions, minimizing voltage overshoot and protecting downstream components (e.g., ICs, sensors, communication interfaces) from damage.
• Fast Response Time: Features sub-nanosecond response speed (<1 ns) to transient events, ensuring rapid activation before damaging voltage levels reach sensitive circuitry.
• High Surge Handling Capacity: Offers robust peak pulse power dissipation, capable of withstanding repetitive transient pulses without performance degradation, suitable for harsh industrial and consumer electronics environments.
• Compact Surface-Mount Package: Utilizes a small SOD-123 package (DRBR suffix), enabling space-saving integration in portable devices, automotive electronics, and IoT modules.

2. Typical Applications

• Consumer Electronics
  • Mobile phones, tablets, and laptops: USB port, audio jack, and charging interface ESD protection
  • Wearable devices: Sensor and Bluetooth/Wi-Fi module transient voltage suppression
  • Smart home appliances: Control board and touch panel surge protection
• Industrial Automation
  • PLC and HMI interfaces: RS-232/RS-485/CAN bus transient protection
  • Industrial sensor systems: Proximity sensor and temperature sensor signal line protection
  • Fieldbus communication modules: Surge protection for industrial Ethernet and PROFIBUS links
• Automotive Electronics
  • In-vehicle infotainment systems: USB-C and HDMI port ESD protection
  • Body control modules (BCM): Switch input and sensor signal surge suppression
  • Telematics units: Cellular and GPS antenna interface transient protection
• Communication Equipment
  • Network routers and switches: Ethernet port ESD/surge protection
  • Wireless access points: RF front-end and antenna interface overvoltage protection
  • IoT gateways: Signal line protection for LoRa, NB-IoT, and Zigbee modules

Key Specifications Summary

• Device Type: Bidirectional TVS Diode
• Working Voltage (V_WM): Customizable based on target application (typical values for low-voltage circuits)
• Clamping Voltage (V_C): Low maximum clamping voltage at rated peak pulse current
• Response Time: < 1 ns
• Peak Pulse Power: High power dissipation capability for repetitive transients
• Package: SOD-123 (Surface-Mount Device)
• Compliance Standards: Meets IEC 61000-4-2 (ESD), IEC 61000-4-4 (EFT), and IEC 61000-4-5 (surge) standards
• Operating Temperature Range: -55°C to +150°C
