Copper Tape Shield Aluminium Conductor Cable 3.6 KV 6kV Medium Voltage Customized
Copper Tape Shield Aluminium Conductor Cable 3.6 KV 6kV Medium Voltage Customized
Specifications
Brand Name :
Aluminium Conductor Cable
Certification :
ISO9001, CE, CCC, RoHS, VDE, cUL, CSA
Place of Origin :
Hebei，China
MOQ :
To be negotiated
Price :
To be negotiated
Payment Terms :
,L/C,T/T
Supply Ability :
100KM/Week
Delivery Time :
7-30 days based on different qty
Packaging Details :
Rolls, Wooden Drums, Steel Drums, Reels or customized
Insulation :
XLPE HPDE
Voltage :
3.6/6 kV
Length :
Customized
Conductor Material :
Copper
Packing :
Neutral Carton Packing or Customized
Application :
Overhead
Description

Copper Tape Shield Aluminium Alloy Conductor Cable 3.6/6kV Medium Voltage



Application



  • Direct Burial Installation‌: Designed for underground installation with steel tape or steel wire armor, providing superior resistance to mechanical pressure, rodent damage, and insect intrusion in soil environments.
  • Industrial Infrastructure‌: Widely used in cable trenches, trays, and conduits within factories, refineries, and mining facilities, where high mechanical stress and electromagnetic interference must be mitigated.
  • Power Distribution Networks‌: Connects substations and switchgear rooms to supply stable power to large-scale commercial buildings, industrial complexes, and urban distribution systems.
  • Harsh Environmental Conditions‌: Engineered with corrosion-resistant sheathing for deployment in chemical plants, coastal zones, and high-humidity industrial areas.




Construction


Copper Tape Shield Aluminium Conductor Cable 3.6 KV 6kV Medium Voltage CustomizedCopper Tape Shield Aluminium Conductor Cable 3.6 KV 6kV Medium Voltage Customized


1.Conductor:Round compacted conductors

2.Conductor Shield:Semi conductive shielding material (below 500mm2)Semi conductive tape+semi conductive shielding material (500mm2 and above)

3.Insulation:Polyvinyl chloride (PVC)

4.Insulation Shield:Peelable semiconducting shielding material

5.Metal Shield Layer:Copper Tape Copper Wire(35kV 500mm above)

6.Filler:Polypropylene(PP) mesh filling rope

7.Binder Tape:Non hygroscopic straps

8. Armouring:Steel Tape(Single core) Galvanized steel tape(3 core)

9. Outer sheath: 90℃ Polyvinyl chloride (PVC)





Specification



Specs
mm²

Conductor diameter
mm

Outer thickness of insulation
±1.0mm

Approx outer diameter of cable
mm

Approx cable weight
kg/km

Specs
mm²

Conductor diameter
mm

Outer thickness of insulation
±1.0mm

Approxi outer diameter of cable
mm

Approx cable weight
kg/km

1×25

6.0±0.1

12.2

21.1

604

3×25

6.0±0.1

12.2

39.0

1909

1×35

6.6±0.2

12.8

21.7

670

3×35

6.6±0.2

12.8

41.6

2167

1×50

7.6±0.2

13.8

22.9

759

3×50

7.6±0.2

13.8

44.6

2485

1×70

9.2±0.2

15.4

24.5

869

3×70

9.2±0.2

15.4

48.2

2899

1×95

10.9±0.2

17.1

26.4

993

3×95

10.9±0.2

17.1

51.6

3338

1×120

12.2±0.2

18.4

27.7

1110

3×120

12.2±0.2

18.4

54.9

3802

1×150

13.6±0.2

19.8

29.2

1253

3×150

13.6±0.2

19.8

58.0

4292

1×185

15.2±0.2

21.4

30.8

1412

3×185

15.2±0.2

21.4

61.9

4861

1×240

17.4±0.2

23.8

33.4

1669

3×240

17.4±0.2

23.8

67.5

5777

1×300

19.5±0.2

26.3

37.5

2306

3×300

19.5±0.2

26.3

73.1

6782

1×400

22.0±0.2

29.2

40.6

2758

3×400

22.0±0.2

29.2

82.7

9086

1×500

24.8±0.2

33.2

45.0

3296

3×500

24.8±0.2

332

90.4

10871

1×630

28.2±0.2

366

48.7

3875

3×630

282±0.2

36.6

98.7

12870

1×800

34.0±0.2

42.4

54.7

4663



OUR FACTORY


Copper Tape Shield Aluminium Conductor Cable 3.6 KV 6kV Medium Voltage Customized


PROJECT

Copper Tape Shield Aluminium Conductor Cable 3.6 KV 6kV Medium Voltage Customized



APPLICATION


Copper Tape Shield Aluminium Conductor Cable 3.6 KV 6kV Medium Voltage Customized


CERTIFICATES


Copper Tape Shield Aluminium Conductor Cable 3.6 KV 6kV Medium Voltage Customized


FAQ


What cable specifications do you offer?
We supply power cables, solar cables, ABC cables, bare conductor, housing wire, instrument and control cables and more.
Are your cables internationally certified?
Yes, our products meet IEC, CE and other regional standards.
What's the lead time for regular orders?
7-30 working days, negotiable for urgent requests.
Can you provide custom cable solutions?
Yes, customized specs, lengths and colors are available.
How do you ensure the quality before delivery?
100% full inspection, with test reports provided.
How are cables packaged for shipment?
Standard cable reels, suitable for sea/land transportation.
What's your after-sales service policy?
12-month warranty with professional technical support.
