Specifications
Model Number :
LS7-2000 /3000 /4000 /5000 /6000
Price :
FOB China USD40,000.00 up/ unit
Payment Terms :
T/T before shipment
Delivery Time :
Lead time 60 days
Packaging Details :
Seacase
Brand Name :
K & G
Place of Origin :
Made in China
MOQ :
1 unit
Description

LS7 -3000 30KW Heavy Duty Grinding Surface Machine

Surface and Knife Grinding Machine, Heavy Duty Grinding Surface Machine, Production Knives Grinding Machine, Production Surface Grinding Machine, Production Knives Grinder

MODEL : LS7- 2000 /3000 /4000 /5000 /6000 30KW/45KW
(Professional Grinding Knives Surface)

1.Machine base, high rigidity steel welded construction.

2.Linear guideways can achieve high precision and greatly enhanced moving accuracy.

3.Worktable features a Stationary Magnetic Chuk, providing sturdy construction and powerful magnetism.

4.Down feed system is driven by a Servo Motor and transmitted through a play free screw and controlled by electronic handwheel. The minimum feed amount is 0.001mm per grid, and the feed is smooth and accurate.

5.Grinding motor, with coolant through motor spindle and quick change wheel flange in design.

6.Grinding tool, ring wheels or segmental heads.

7.Traverse drive is driven by a Variable Frequency Motor, using gear and rack transmission with stepless speed regulation, achieving a stable operation speed of 1-25 meters/min.

8.Coolant water through the hollow motorshaft and from the sides.

9.Lubrication system features an adjustable central electrical lubrication mechanism, which can adjust the automatic oil supply to the enclosed working area.

10.Electric cabinet equipped with a touch screen and control interface, is installed on the grinding head carriage.

Technical Parameter :

Grinding length 3000 /4000 /5000 /6000mm
Stationary magnetic chuk 3000 /4000 /5000 /6000mm x 320/350mm
Pass height 250mm
Down feed 0.001mm
Traverse drive speed 1-25 m/min
Guideways Linear guideways
Grinding wheel Ø475 Segmental heads (8 pcs)
Gross power 3 phase / 380V / 50HZ
Grinding motor 30KW / 45KW (1500 RPM)
Down feed motor 0.75KW (Servo Motor)
Traverse drive motor 2.2KW ( Variable Frequency Motor)
Water pump 100 L/min
Net weight 7000 up /kg
Machine main size To be advised per model
Colour Blue + White
