MOOG D634-319C Servo Valve 40 L/min Rated flow rate Direct Acting Design
MOOG D634-319C Servo Valve 40 L/min Rated flow rate Direct Acting Design
MOOG D634-319C Servo Valve 40 L/min Rated flow rate Direct Acting Design
MOOG D634-319C Servo Valve 40 L/min Rated flow rate Direct Acting Design
Specifications
Brand Name :
MOOG
Model Number :
D634-319C
Certification :
Brand new original
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 pcs
Delivery Time :
5-7 days
Operatingtemperature :
-20°C to 70°C
Function :
Control valve actuator position
Responsetime :
Less than 1 second
Supplypressure :
20-30 psi / 1.4-2.0 bar
Feedbacksignal :
Potentiometer / LVDT / Digital feedback
Inputsignal :
4-20 mA / 0-10 V / HART / Fieldbus
Application :
Control of industrial control valves in process industries
Powersupply :
24 V DC / 110 V AC / 220 V AC
Mountingtype :
Direct mount / Remote mount
Outputpressurerange :
3-15 psi / 0.2-1.0 bar
Productname :
Valve Positioners
Type :
Electro-pneumatic / Pneumatic / Digital
Protectionclass :
IP65 / NEMA 4
Material :
Aluminum alloy / Stainless steel
Accuracy :
±1% of full scale
Description
MOOG D634-319C Servo Valve
Core Specifications
Hydraulic Parameters
Parameters Indicators Description
Model D633-319C Complete Model: D633-319C
Type Direct-acting servo valve (DDV) Directly driven by linear force motor, no pilot stage
Maximum working pressure 350 bar (35 MPa) P/A/B ports; T port ≤50 bar (no Y port) / ≤210 bar (with Y port)
Rated flow rate 40 L/min @35 bar Valve pressure drop (single port)
Maximum flow rate 75 L/min Overload flow rate
Step response ≤12 ms 0->100% stroke Moog
Frequency response 40-60 Hz ±100% input signal
Control accuracy Hysteresis < 0.2%, resolution < 0.1%
Electrical Parameters
Parameters Indicators Description
Power Supply 24 VDC (19-32 VDC)
Maximum Current 1.2 A
Control Signal ±10 V / ±10 mA / 4-20 mA Built-in Amplifier, Analog Interface
Valve Core Feedback Built-in Displacement Sensor (LVDT) Closed-Loop Control
Protection Rating IP65 (with standard plug)
Mechanical and Installation
Parameters Indicators Description
Installation Standard ISO 4401 Size 03 (CETOP 03)
Installation Method Flange Fixed Any Installation Position
Valve Body Material Steel
Sealing NBR/FKM Oil-resistant and High-Temperature Resistant
Weight ≈2.5 kg
Power Off Position Spring Centering Safe Position
Operating Conditions & Fluid Requirements
Working Medium Mineral oil (DIN 51524), Water Glycol, Phosphate Ester
Oil Viscosity Recommended 15-100 mm²/s; Permissible 5-400 mm²/s
Cleanliness ISO 4406 <15/12 (Reliable); <14/11 (Long Life)
Internal Leakage ≈1.2 L/min (Zero Overlap)
Ambient Temperature -20°C ～ +60°C; Oil: -20°C ～ +80°C
Vibration 30g, Triaxial
Supply and Warranty
  • Delivery Time: Regularly 8-12 weeks, some in stock
  • Warranty: 12 months from the manufacturer
  • Origin: USA / Germany
Core Advantages
  • Direct-acting Design: No pilot-stage leakage, dynamic response independent of oil supply pressure, strong anti-contamination capability
  • Linear Force Motor: Bidirectional active drive, high thrust, overcomes flow and friction, precise positioning
  • Built-in Electronic Closed-Loop: Real-time valve core position feedback, high control accuracy, low hysteresis, and good stability
  • Low Power Consumption: Low current near the valve core center position, low standby power consumption
  • Wide Operating Condition Adaptability: High pressure, wide temperature range, wide viscosity range, suitable for harsh industrial environments
  • Easy Maintenance: No pilot filter, reduces maintenance points, long service life
Typical Applications
  • Injection Molding Machines, Die Casting Machines, Hydraulic Presses
  • Material Testing Machines, Servo Testing Stands
  • Industrial Robots, Automated Production Lines
  • Metallurgical Equipment, Papermaking Machinery
  • Aerospace Testing Systems
