Specifications
Brand Name :
EDL
Model Number :
M412P-16
Certification :
ISO9001, ISO14001, RoHS
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
30,000pcs/day
Delivery Time :
3-15days
Packaging Details :
Carton
Name :
Equipment Casters
Wheel Diameter :
2inch(50mm)
Tread Material :
PA
Mounting Type :
Rigid/Swivel/Brake
Dynamic Load :
250kg
Mounting Height :
70mm
Frame Material :
Cold-Rolled Plate
Plate Thickness :
2mm
Bracket Thickness :
2mm
Surface Treatment :
Zinc Coating
Bracket Width :
41mm
Wheel width :
35mm
Bearing :
Double ball bearings
Tread Color :
Black
Applicable Temperature :
-20℃～100℃
Tread Hardness :
67D
Description

EDL 2inch Plate PA Equipment Caster by Rigid, Swivel and Brake type M412P-16 250kg Road


The EDL 2-Inch Plate PA Equipment Caster (Model M412P-16) is engineered for heavy-duty performance in industrial and equipment-intensive environments. Constructed from high-strength black PA (Nylon), this caster delivers exceptional durability, wear resistance, and impact tolerance, making it ideal for long-term use under heavy loads. With a maximum load capacity of 250kg, it is specifically designed to support large machinery and equipment where stability and strength are critical. The caster is available in rigid, swivel, and brake configurations, offering flexible movement control depending on application needs. Its plate-mount design ensures a secure and stable installation on flat surfaces, while the low-profile structure lowers the equipment’s center of gravity, improving balance and reducing the risk of tipping. Whether installed on industrial platforms, mobile workstations, or other heavy devices, the M412P-16 offers a perfect combination of maneuverability, strength, and safety. With its clean black finish and robust build, this caster is a dependable solution for high-load, low-clearance applications requiring both mobility and precision.

Wheel ltem No.Instruction

Wheel

Item No.

 Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

 Core Tread Bearing

Applicable

Temperature

 Hardness
M412-16 2" 50mm 35mm 41mm 250Kg /

PA

Double ball

bearing 6001

 -20℃～100℃ 67D


EDL 2 Inch Plate Equipment Caster By Rigid Swivel Brake Type M412P-16 250kg RoadEDL 2 Inch Plate Equipment Caster By Rigid Swivel Brake Type M412P-16 250kg Road

EDL 2 Inch Plate Equipment Caster By Rigid Swivel Brake Type M412P-16 250kg RoadEDL 2 Inch Plate Equipment Caster By Rigid Swivel Brake Type M412P-16 250kg Road

EDL 2 Inch Plate Equipment Caster By Rigid Swivel Brake Type M412P-16 250kg RoadEDL 2 Inch Plate Equipment Caster By Rigid Swivel Brake Type M412P-16 250kg Road

EDL 2 Inch Plate Equipment Caster By Rigid Swivel Brake Type M412P-16 250kg Road

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.
