Specifications
Brand Name :
EDL
Model Number :
M4125P-16
Certification :
ISO9001, ISO14001, RoHS
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
30,000pcs/day
Delivery Time :
3-15days
Packaging Details :
Carton
Name :
Equipment Casters
Wheel Diameter :
2.5inch(65mm)
Tread Material :
PA
Mounting Type :
Rigid/Swivel/Brake
Dynamic Load :
300kg
Mounting Height :
85mm
Frame Material :
Cold-Rolled Plate
Plate Thickness :
2mm
Bracket Thickness :
2mm
Surface Treatment :
Zinc Coating
Bracket Width :
41mm
Wheel width :
35mm
Bearing :
Double ball bearings
Tread Color :
Black
Applicable Temperature :
-20℃～100℃
Tread Hardness :
67D
Description

EDL Equipment Casters 2.5 Inch Plate Casters M4125P-16 by Rigid,Swive,Brake Type


The EDL 2.5-Inch Plate Equipment Caster (Model M4125P-16) is built to meet the demands of high-load industrial applications, offering enhanced mobility and durability. Crafted from premium black nylon (PA), it resists wear, deformation, and impact, making it well-suited for both static and dynamic heavy-duty use. With a load rating of up to 250kg, it ensures dependable support for larger machines, workstations, or mobile platforms. The caster comes in rigid, swivel, and brake options, providing versatile movement control depending on operational needs. Its plate mounting system allows for firm attachment to flat equipment bases, while the slightly larger 2.5-inch wheel diameter improves ground clearance and rolling ease. Designed with a focus on both safety and performance, this caster helps lower the equipment’s center of gravity for better balance during transport. Whether used in workshops, labs, or production facilities, the M4125P-16 combines strength and adaptability to meet the demands of industrial mobility.

Wheel ltem No.Instruction

Wheel

Item No.

 Size

Wheel

Diameter

Wheel

Width

Bracket

Width

Load

Capacity

 Core Tread Bearing

Applicable

Temperature

 Hardness
M4125-16 2.5" 65mm 35mm 41mm 300Kg /

PA

Double ball

bearing 6001

 -20℃～100℃ 67D

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake TypeEDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake TypeEDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake TypeEDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type

EDL 2.5 Inch Plate Heavy Equipment Casters M4125P-16 By Rigid Swive Brake Type

FAQ:

Q: Are you manufacturer or trading company?
A: We are caster wheels manufacturer since 1987.

Q: Where is your factory? Can I visit ?
A: Our factory is at Taizhou, Zhejiang, China. 2 hours by car from Yiwu. Welcome to visit.

Q: What is your delivery time?
A: Normally within 1 week. It's up to the order quantity.

Q: What is the term of payment?
A: Payment terms: 30%(it's stand product, for customized product it's 50%) of deposit upon signing the PI and the rest will be cleared by T/T before delivery.

Q: Are samples available?
A: Yes, sample is fine at any time, negotiable.
