Thick Film Chip Resistor VO SCR0603J0R Lead Free Halogen Free Rated Power 1 Watt Voltage 75 Volts
Thick Film Chip Resistor VO SCR0603J0R Lead Free Halogen Free Rated Power 1 Watt Voltage 75 Volts
Specifications
Power(Watts) :
100mW
Resistance :
0Ω
Voltage Rating :
75V
Operating Temperature :
-55℃~+155℃
Type :
Thick Film Resistor
Temperature Coefficient :
-
Tolerance :
±5%
Description :
100mW 0Ω 75V Thick Film Resistor ±5% 0603 Chip Resistor - Surface Mount RoHS
Mfr. Part # :
SCR0603J0R
Model Number :
SCR0603J0R
Package :
0603
Description

Product Overview

This document specifies the SCR series thick film chip resistors, which are lead-free and halogen-free. These resistors are general-purpose and designed for a wide range of applications. The product is manufactured by Anhui Xiangsheng Technology Co., Ltd.

Product Attributes

  • Brand: VIC (implied by website www.vicovo.com)
  • Origin: Anhui, China
  • Material: Thick Film
  • Certifications: RoHS compliant (lead-free, halogen-free)

Technical Specifications

TypeRated PowerMax. Rated VoltageMax. Overload VoltageT.C.R (ppm/)Resistance Range (F/D 1%/0.5%)Resistance Range (J 5%)Resistance Range (JUMPER 0)Operating Temperature RangeDimensions (L x W x H) mm
SCR 02011/1W25V50V1001R9.11R9.150m MAX.-55~ +1250.600.03 x 0.30.03 x 0.230.03
SCR 04021/1W50V100V10010R1M10R10M50m MAX.-55~ +1551.000.10 x 0.500.05 x 0.300.05
SCR 06031/1W75V150V10010R1M10R10M50m MAX.-55~ +1551.600.10 x 0.800.10 x 0.450.10
SCR 08051/1W150V300V10010R1M10R10M50m MAX.-55~ +1552.000.10 x 1.250.10 x 0.500.10
SCR 12061/1W200V400V10010R1M10R10M50m MAX.-55~ +1553.050.10 x 1.550.10 x 0.500.10
SCR 12101/1W200V400V10010R1M10R10M50m MAX.-55~ +1553.050.10 x 2.600.15 x 0.550.10
SCR 20103/3W200V400V10010R1M10R10M50m MAX.-55~ +1555.000.10 x 2.500.15 x 0.550.10
SCR 25121/1W200V400V10010R1M10R10M50m MAX.-55~ +1556.350.10 x 3.100.15 x 0.550.10

2205131800_VO-SCR0603J0R_C3017805.pdf
