Polypropylene film capacitor Jimson MAC255K450A01 designed for starting running and power factor correction in AC motors
Polypropylene film capacitor Jimson MAC255K450A01 designed for starting running and power factor correction in AC motors
Specifications
Capacitance :
2.5uF
Ratings :
-
Voltage(AC) :
450V
Tolerance :
±10%
Description :
2.5uF ±10% 450V Safety Capacitor Through Hole,P=31.5mm
Mfr. Part # :
MAC255K450A01
Model Number :
MAC255K450A01
Package :
Through Hole,P=31.5mm
Description

Product Overview

The JIMSON MAC series capacitors are designed for AC motor applications, providing starting, running, and power factor correction functions. They feature high current endurance, non-inductive construction, and self-healing properties, making them suitable for a wide range of appliances and lighting systems. Manufactured by (JIMSON ELECTRONICS (XIAMEN) CO.,LTD.) in China, these capacitors comply with RoHS standards.

Product Attributes

  • Brand: JIMSON
  • Origin: Xiamen, China
  • Product Name: Capacitor
  • Type: MAC
  • Material (Dielectric): Polypropylene film
  • Material (Electrodes): Vacuum evaporated metal
  • Coating: Reinforced flame retardant plastic case sealed with epoxy resin (UL94V-0)
  • Leads: Radial leads of tinned wire/insulation flexible wire
  • Color: BLACK
  • Certifications: UL810 (Canada/America E249178), CQC (China CQC04002010184)
  • Reference Standards: IEC 60252, UL810, GB/T3667.2

Technical Specifications

Rated CapacitanceCapacitance ToleranceRated VoltageDielectricDissipation Factor (DF)Insulation Resistance (T-T)EnduranceClimatic CatalogueConstruction
1.0uFK (10%)450VACPolypropylene film0.2% (at 20, 1kHz)2000M (C<0.47F)600 hours with 125% rated voltage at 70 (C/C5%; IR50%)25/70/21Non-inductive
2.0uFK (10%)450VACPolypropylene film0.2% (at 20, 1kHz)1000M (C0.47F)600 hours with 125% rated voltage at 70 (C/C5%; IR50%)25/70/21Non-inductive
2.5uFK (10%)450VACPolypropylene film0.2% (at 20, 1kHz)1000M (C0.47F)600 hours with 125% rated voltage at 70 (C/C5%; IR50%)25/70/21Non-inductive
4.0uFJ (5%)500VACPolypropylene film0.2% (at 20, 1kHz)1000M (C0.47F)600 hours with 125% rated voltage at 70 (C/C5%; IR50%)25/70/21Non-inductive

2410121458_Jimson-MAC255K450A01_C434401.pdf
