Surface Mount Multilayer Ceramic Capacitors Chinocera HHV0805R7101K101NTHJ for High Voltage Circuits
Surface Mount Multilayer Ceramic Capacitors Chinocera HHV0805R7101K101NTHJ for High Voltage Circuits
Specifications
Voltage Rating :
100V
Capacitance :
100pF
Temperature Coefficient :
X7R
Tolerance :
±10%
Description :
100pF ±10% 100V Ceramic Capacitor X7R 0805
Mfr. Part # :
HHV0805R7101K101NTHJ
Model Number :
HHV0805R7101K101NTHJ
Package :
0805
Description

Product Overview

The HHV series of Multilayer Ceramic Capacitors (MLCCs) from Suining Hongming Huaci Technology Co., Ltd. are designed for high-density, high-efficiency surface mount applications. These capacitors are manufactured using NP0 (C0G, C0H) and X7R materials, offering superior electrical performance and high reliability. They are suitable for mid-to-high voltage applications ranging from 100V to 3000V, with available sizes from 0402 to 1812. Key features include high voltage in a given case size, high stability, and reliability, making them ideal for applications such as analog and digital modems, LAN/WAN interfaces, voltage multipliers, DC-DC converters, and back-lighting inverter circuits.

Product Attributes

  • Brand: HHV Series
  • Manufacturer: Suining Hongming Huaci Technology Co., Ltd.
  • Origin: China
  • Materials: NP0 (C0G, C0H), X7R

Technical Specifications

Category Specification Details
Product Name Multilayer Ceramic Capacitors HHV Series
Series Mid-High Volts Series 100V ~ 3000V
Available Sizes (Inch) 0402 ~ 1812 (1005 ~ 4532 mm)
Dielectric Materials NP0 (C0G, C0H), X7R
Temperature Coefficient/Characteristics C0G/C0H: 30 ppm/ (-55125) C0H: 60 ppm/ (-55125)
X7R: 15% (-55125) X7S: 22% (-55125)
External Dimensions (mm) 0402 (1005) L: 1.000.05, W: 0.500.05, T: 0.500.05
0603 (1608) L: 1.600.20, W: 0.800.20, T: 0.800.20
0805 (2012) L: 2.000.20, W: 1.250.20, T: 0.700.10 / 0.800.20
1206 (3216) L: 3.200.20, W: 1.600.20, T: 0.800.20
1210 (3225) L: 3.200.30, W: 2.500.20, T: 1.250.20
1808 (4520) L: 4.50.40, W: 2.00.25, T: 1.250.20
1812 (4532) L: 4.50.40, W: 3.20.30, T: 1.250.20
Capacitance Range (Example C0G/C0H) 0.5pF to 0.10F Varies by size and voltage rating
Capacitance Range (Example X7R) 100pF to 4.7F Varies by size and voltage rating
Rated Voltage 100 Vdc to 3000 Vdc Specific values depend on series and size
Tolerance 0.05pF, 0.1pF, 0.25pF, 0.5pF, 1%, 2%, 5%, 10%, 15%, 20%, -20%~+50%
Packaging Paper Taping, Embossed Taping, Bulk Reel sizes: 7Inch, 13Inch
Storage Conditions Temperature: 5~40, Relative Humidity: 20%~70% Guaranteed solderability period: 6 months

2410121646_Chinocera-HHV0805R7101K101NTHJ_C5186764.pdf
