Three channel common mode EMI filter with integrated ESD protection Nexperia PCMF3HDMI2SZ device
Three channel common mode EMI filter with integrated ESD protection Nexperia PCMF3HDMI2SZ device
Three channel common mode EMI filter with integrated ESD protection Nexperia PCMF3HDMI2SZ device
Three channel common mode EMI filter with integrated ESD protection Nexperia PCMF3HDMI2SZ device
Three channel common mode EMI filter with integrated ESD protection Nexperia PCMF3HDMI2SZ device
Three channel common mode EMI filter with integrated ESD protection Nexperia PCMF3HDMI2SZ device
Specifications
Number of Channels :
6
Resistance :
3Ω
Operating Temperature :
-40℃~+85℃
Description :
6 3Ω UFBGA-15 EMI/RFI Filters (LC, RC Networks) RoHS
Mfr. Part # :
PCMF3HDMI2SZ
Model Number :
PCMF3HDMI2SZ
Package :
UFBGA-15
Description

Product Overview

Common-mode ElectroMagnetic Interference (EMI) filters with integrated ElectroStatic Discharge (ESD) protection for one, two, and three differential channels. These devices are designed to provide low insertion loss for high-speed differential signals while attenuating unwanted common-mode signals. Each channel features integrated coils and diodes for ESD protection up to 15 kV. They offer superior common-mode suppression and RF performance compared to discrete solutions, with high symmetry between line pairs. Available in industry-standard Wafer Level Chip Scale Packages (WLCSP) for a smaller footprint.

Product Attributes

  • Brand: Nexperia
  • Certifications: IEC 61000-4-2, IEC 60134

Technical Specifications

Type NumberNumber of ChannelsPackage NameESD Protection (Contact Discharge)Common-Mode Insertion Loss (800 MHz)Differential-Mode Insertion Loss (1 MHz)Cut-off Frequency
PCMF1HDMI2S1WLCSP515 kV-12 dB0.3 dB6 GHz
PCMF2HDMI2S2WLCSP1015 kV-12 dB0.3 dB6 GHz
PCMF3HDMI2S3WLCSP1515 kV-12 dB0.3 dB6 GHz

2411121056_Nexperia-PCMF3HDMI2SZ_C552021.pdf
