Nexperia PCMF1HDMI2BA-C EMI filter designed to protect differential channels from EMI and ESD events
Nexperia PCMF1HDMI2BA-C EMI filter designed to protect differential channels from EMI and ESD events
Nexperia PCMF1HDMI2BA-C EMI filter designed to protect differential channels from EMI and ESD events
Nexperia PCMF1HDMI2BA-C EMI filter designed to protect differential channels from EMI and ESD events
Nexperia PCMF1HDMI2BA-C EMI filter designed to protect differential channels from EMI and ESD events
Nexperia PCMF1HDMI2BA-C EMI filter designed to protect differential channels from EMI and ESD events
Specifications
Number of Channels :
2
Resistance :
2.2Ω
Operating Temperature :
-40℃~+125℃
Description :
2 2.2Ω UFBGA-5 EMI/RFI Filters (LC, RC Networks) RoHS
Mfr. Part # :
PCMF1HDMI2BA-CZ
Model Number :
PCMF1HDMI2BA-CZ
Package :
UFBGA-5
Description

Product Overview

The PCMFxHDMI2BA-C series are common-mode EMI filters with integrated bidirectional ESD protection for differential channels. They are designed to attenuate unwanted common-mode signals while providing low insertion loss for differential high-speed signals. Each channel consists of two signal lines coupled by integrated coils, and integrated diodes offer ESD protection up to 15 kV on each signal line. These filters are suitable for various applications requiring differential data line protection and EMI suppression.

Product Attributes

  • Brand: Nexperia
  • Certifications: IEC 61000-4-2, IEC 60134

Technical Specifications

Type NumberNumber of ChannelsPackage NameESD Protection (Contact Discharge)Differential Mode Cut-off FrequencyChannel Series Resistance (Single Line)
PCMF1HDMI2BA-C1WLCSP515 kV10 GHz2.2 (Typ)
PCMF2HDMI2BA-C2WLCSP1015 kV10 GHz2.2 (Typ)
PCMF3HDMI2BA-C3WLCSP1515 kV10 GHz2.2 (Typ)
