Specifications
Description :
EMI/RFI Filters (LC, RC Networks) RoHS
Mfr. Part # :
PCMF3HDMI2S,087
Model Number :
PCMF3HDMI2S,087
Description

Product Overview

Common-mode ElectroMagnetic Interference (EMI) filters with integrated ElectroStatic Discharge (ESD) protection for one, two, and three differential channels. These devices are engineered to provide low insertion loss for high-speed differential signals while attenuating unwanted common-mode signals. Each differential channel utilizes integrated coils for signal coupling and diodes for ESD protection up to 15 kV on each signal line. They offer superior common-mode suppression, excellent RF performance, and high symmetry between line pairs, making them ideal for modern high-speed interfaces.

Product Attributes

  • Brand: Nexperia
  • Certifications: IEC 61000-4-2, IEC 60134

Technical Specifications

Type NumberNumber of ChannelsPackage NameESD Protection (kV)Common-Mode Insertion Loss (dB) @ 800 MHzCommon-Mode Insertion Loss (dB) @ 2.6 GHzCommon-Mode Insertion Loss (dB) @ 5 GHzDifferential-Mode Insertion Loss (dB) @ 1 MHzDifferential-Mode Cut-off Frequency (GHz)
PCMF1USB301WLCSP5±15 (contact)-12-38-180.36
PCMF2USB302WLCSP10±15 (contact)-12-38-180.36
PCMF3USB303WLCSP15±15 (contact)-12-38-180.36

2411271824_Nexperia-PCMF3HDMI2S-087_C5823922.pdf
