Two channel common mode EMI filter Nexperia PCMF2HDMI14SZ with ESD protection and low insertion loss
Two channel common mode EMI filter Nexperia PCMF2HDMI14SZ with ESD protection and low insertion loss
Two channel common mode EMI filter Nexperia PCMF2HDMI14SZ with ESD protection and low insertion loss
Two channel common mode EMI filter Nexperia PCMF2HDMI14SZ with ESD protection and low insertion loss
Specifications
Description :
WLCSP-10 EMI/RFI Filters (LC, RC Networks) RoHS
Mfr. Part # :
PCMF2HDMI14SZ
Model Number :
PCMF2HDMI14SZ
Package :
WLCSP-10
Description

Product Overview

Common-mode ElectroMagnetic Interference (EMI) filters with integrated ElectroStatic Discharge (ESD) protection for one, two, and three differential channels. These devices are engineered to offer low insertion loss for differential high-speed signals on each channel while effectively attenuating unwanted common-mode signals. Each differential channel features two signal lines coupled by integrated coils. Integrated diodes provide protection to downstream components from ESD voltages up to 15 kV on each signal line.

Product Attributes

  • Brand: Nexperia
  • Certifications: IEC 61000-4-2, IEC 61000-4-5

Technical Specifications

Type numberNumber of channelsPackage NameDescriptionESD Protection (contact discharge)Common-mode Insertion Loss (800 MHz)Differential-mode Insertion Loss (1 MHz)Cut-off Frequency
PCMF1HDMI14S1WLCSP5wafer level chip-size package; 5 bumps (2-1-2)15 kV-12 dB0.3 dB6 GHz
PCMF2HDMI14S2WLCSP10wafer level chip-size package; 10 bumps (4-2-4)15 kV-21.5 dB (1.7 GHz)0.3 dB6 GHz
PCMF3HDMI14S3WLCSP15wafer level chip-size package; 15 bumps (6-3-6)15 kV-31.5 dB (3 GHz)0.3 dB6 GHz

2304140030_Nexperia-PCMF2HDMI14SZ_C552016.pdf
