Specifications
Description :
SOP-4 Triac, SCR Output Optoisolators RoHS
Mfr. Part # :
KLM3084-TA-AW-T04
Model Number :
KLM3084-TA-AW-T04
Package :
SOP-4
Description

Product Overview

The KLM308X is a zero-crossing triac photocoupler designed for interfacing logic systems with 110 to 240 VAC powered equipment. It comprises a GaAs infrared emitting diode and a zero-cross triac transistor, suitable for applications like solid-state relays, industrial controls, motors, solenoids, and consumer appliances.

Product Attributes

  • Brand: Kinglight
  • Product Series: KLM308X
  • Certifications: EU REACH, RoHS
  • Material: Halogen-free (Br < 900ppm, Cl < 900ppm, Br+Cl < 1500ppm), Pb-free
  • Grade: Consumer-grade

Technical Specifications

ParameterSymbolKLM3082 (Typ.)KLM3083 (Typ.)KLM3084 (Typ.)UnitCondition
Electrical-Optical Characteristics
Peak breakdown voltage800V
Isolation VoltageViso3750VrmsAC for 1 minute, R.H.= 40 ~ 60% R.H.
Operating TemperatureTOPR-40 to +110
Storage TemperatureTSTG-55 to +150
Electrical Characteristics
Forward voltageVF--1.5VIF=30mA
Reverse currentIR--10AVR=6V
Off-state Output Terminal VoltageVDRM800V
On-State RMS CurrentIT(RMS)70mA
Peak On-state VoltageVTM--3VITM=100mA peak
Critical Rate of Rise of Off-state Voltagedv/dt1000V/s
Inhibit VoltageVINH--20VIF= Rated IFT
Leakage Current in Inhibit StateIDRM2--1000AIF= Rated IFT, VDRM=Rated VDRM, off state
Transfer Characteristics
LED Trigger CurrentIFT1053mAMain terminal Voltage=3V
Holding CurrentIH-280-A

2507171700_Kinglight-KLM3084-TA-AW-T04_C49374868.pdf
