Threaded Destaco Swing Clamps Friendly Installation Upper Flanged Mounting
Threaded Destaco Swing Clamps Friendly Installation Upper Flanged Mounting
Specifications
Brand Name :
Jiayan
Model Number :
HAU
Certification :
ISO9001:2008
Place of Origin :
Dongguan China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,PayPal
Supply Ability :
1000 pcs per week
Delivery Time :
7 days
Packaging Details :
poly bag and carton box
Material :
Aluminum alloy
Bore of Cylinder :
50 mm
Diameter of Piston :
20mm
Power :
Pneumatic
Structure :
Piston Cylinder
Maximum Stroke :
29mm
Description

Air Rotary Swing Clamp Friendly Installation Threaded Body Upper Flanged Mounting

1.The bores of this kind of product are including 32,40,50 and 63;
2.Double acting type
3.The total stroke is equal to the sum of a swing stroke and a clamping stroke
4.Clamping type : single arm and double arms
5.The material of the cylinder is aluminum alloy
6.If you need to increase the length of the clamping arm ,please don't exceed 1.5
times of the original length
Specification
Bore of Cylinder (mm)
?32
?40
?50
?63
Bore of Pison
?20
?20
?20
?25
Swing stroke (mm)
14
Clamping stroke
15
Pressure area pull/push cm ?2;
4.9/8.04
9.43/12.57
16.49/19.63
28.03/31.17
Theoretical Clamping
5kg/ cm ?2;
25kgs
47kgs
85kgs
130kgs
Fluid
Filtered air
Max operation pressure
10kg/cm?2;
Range of pressure (kg/ cm ?2; )
4-7kg/cm?2;
Rotating directio
Turn right R or Turn left L
Rotating angle
Standard angle 90°(±2°),optional angle 0°(±2°) 45°(±2°) 60° (±2°)
Acting type
Double acting
Threaded Destaco Swing Clamps Friendly Installation Upper Flanged Mounting
