Specifications
Brand Name :
Seric
Model Number :
SQP Series
Certification :
CE, ISO
Place of Origin :
Guangzhou, China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T,L/C,Western Union
Supply Ability :
5000
Delivery Time :
1-15 days
Packaging Details :
Carton Box/Wooden Case
After Warranty Service :
Online Support
OEM :
Accept
Condition :
100% Brand-new
Quality :
High-Quality
Application :
Industrial Machinery
Selling Units :
Single item
Description

SQP Series Double Vane Pump SQP21 SQP31 SQP41 SQP32 SQP42 SQP43 Low Noise

Features

Double pump combination of differing displacements permits simper circuit design compared to systems using one large displacement pump and provides greater flexibility in circuit design with the benefit of low noise levels.

SQP21, SQP31, SQP32, SQP41, SQP42, SQP43, each section pump flow code, see single pump technical data.

Specifications

Model
 First Pump (Shaft Side) Second Pump (Pump Cover Side)
Displacement Mark Displacement at 1000min⁻¹ and 0.7MPa
(L/min)		 Maximum Operating Pressure
(MPa)		 Displacement Mark Displacement at 1000min⁻¹ and 0.7MPa
(L/min)		 Maximum Operating Pressure
(MPa)		 Maximum Speed
(min⁻¹)		 Minimum Speed
(min⁻¹)
SQP(S)21 10 32.5 17.5
*(14)		 2 7.5 14
*(14)		 1800
▲(1200)
*(1200)		 600
12 38.3 3 10.2
14 43.3 4 12.8 17.5
*(14)
15 46.7 5 16.7
17 52.5
19 59.2
21 65
SQP(S)31 17 53.3 17.5
*(14)		 6 19.2
21 66.7 7 22.9
25 79.2 8 26.2
30 95 9 28.3
32 100
35 109
38 118
SQP(S)41 30 96 17.5
*(14)		 11 35
35 109 12 37.9 16
*(14)
38 128 14 44.2 14
*(14)
42 134
50 156
60 189
SQP(S)32 17 53.3 17.5
*(14)		 10 32.5 17.5
*(14)
21 66.7 12 38.3
25 79.2 14 43.3
30 95 15 46.7
32 100
35 109
38 118
SQP(S)42 30 96 17.5
*(14)		 17 52.5
35 109 19 59.2
38 128 21 65
42 134
50 156
60 189
SQP(S)43 30 96 17.5
*(14)		 17 53.3 17.5
*(14)
35 109 21 66.7
38 128 25 79.2
42 134 30 95
42 134 32 100
50 156 35 109
60 189 38 118

*Maximum operating pressure and maximum speed for F3-SQP(S) when using phosphate ester hydraulic oil

▲Maximum speed for F11-SQP(S) when using water - glycol hydraulic oil
