RY31B Type Ultra High Frequency Oxide Film Resistor
RY31B Type Ultra High Frequency Oxide Film Resistor
RY31B Type Ultra High Frequency Oxide Film Resistor
RY31B Type Ultra High Frequency Oxide Film Resistor
Specifications
Brand Name :
HUAXING
Model Number :
RY31B
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Description

RY31B type ultra high frequency oxide film resistor

1. Purpose and characteristics:

The product has wide resistance range, good stability, pulse resistance, overload capacity, can withstand up to 300kv pulse voltage, the product resistance is as high as 3kΩ±3%, and after multi-stage transmission, the conversion curve waveform has no obvious change.

2. Packaging form:

porcelain shell

3. External size:

RY31B Type Ultra High Frequency Oxide Film Resistor

Rated power consumption at 25℃

W

nominal candle-power

Ω

 outline dimension mm

maximum weight

(g)
Lmax D max
1000 3k <300 <50 1000
90

4. Main technical indicators:

25℃Rated

power dissipation

W

nominal

resistance

Ω

nominal candle-power

allowable deviation

%

Pulse operating voltage

kv

Pulse limit voltage

kv

Resistance temperature

characteristic

×10-6/℃

interelectrode

electric capacity

pF
1000 3k ± 3 200 300 ±600 ≤30
90 230 <50

Note: a, the rated power consumption of the resistor is the DC power consumption when the working medium is transformer oil at 25℃;

b) The working medium is transformer oil for the 3kΩ resistor, the first peak of the pulse waveform is a quasi-sine attenuated wave with a pulse width of 3±1μs and a repetition rate of 1/600Hz; for the 90Ω resistor, the pulse waveform is a square wave with a pulse width of 100+20-30ns and a repetition rate of 1/600Hz
