RY31A Type Ultra High Frequency Oxide Film Resistor
RY31A Type Ultra High Frequency Oxide Film Resistor
RY31A Type Ultra High Frequency Oxide Film Resistor
RY31A Type Ultra High Frequency Oxide Film Resistor
RY31A Type Ultra High Frequency Oxide Film Resistor
RY31A Type Ultra High Frequency Oxide Film Resistor
RY31A Type Ultra High Frequency Oxide Film Resistor
RY31A Type Ultra High Frequency Oxide Film Resistor
Specifications
Brand Name :
HUAXING
Model Number :
RY31A
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Description

RY31A type ultra high frequency oxide film resistor

1. Purpose:

used in ultra high frequency measurement circuit or used as an independent component and device (such as attenuator, divider, simulation load, etc.).

2. Packaging form:

no packaging

3. External size:

RY31A Type Ultra High Frequency Oxide Film Resistor

Note: Mark the product end face.

Resistor model Shape size (mm) maximum weight (g)
Lmax Dmax dmax l
RY31A-10 76.5 Φ15.3 Φ10.7 5±0.5 22
RY31A-25 12 0 Φ25.2 Φ17.9 10±1 80
RY31A-50 16 2.5 Φ25.2 Φ17.9 10±1 120
RY31A-100 203 Φ35.3 Φ23.1 12±1.2 280
RY31A-150 303 Φ35.3 Φ23.1 20±2 430

4. Main technical indicators

power rating

(W)

nominal candle-power

(Ω)

accuracy class

(%)

Pulse test voltage

(k v)

temperature coefficient

× 10-6/℃
10 50

±5%(J)

±10%(K)

 3.2

20℃~125℃

± 400
75 4
20 50 5
75 6.5
50 50 7.5
75 8.7
100 50 11
75 12.5
150 50 12.5
75 12.5
