DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
Specifications
Price :
$284.99-310.99 / set
Cylinder arrangement :
Single
Brand Name :
DLA
Output :
3.8HP
Compression Ratio :
8:1
Place of Origin :
Shandong, China
speed range :
1800-7000 RPM
private mold :
No
Model Number :
DLA32
Fuel :
Gasoline + 2T synthetic oil
Pulling force :
9KG/1000 Meter altitude
Lubrication Ratio :
25:1~30: 1(trial run) 40: 1~50:1(normal flying)
Cylinder Bore/ Stroke :
37MM/30MM
Exhaust amount :
32cc
MOQ :
2 sets
Description
Product Description
Product Description
This engine is mainly used for fixed-wing with take-off weights (including Gasoline) not more than 9 KGS. Its crankcase,
crankshaft, central screws are all made of domestic high-performance materials by CNC processing method. With beautiful appearance, high-precision, drop resistance, fatigue resistance, good stability, strong power performance.
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine
DLA 32 DLA32 CNC Processed 32cc Single Cylinder Engine for RC Model Plane UAV Engine

Specification.

Exhaust amount: 32cc
Output: 3.8HP
Cylinder Bore/ Stroke: 37MM/30MM
speed range: 1800-7000 RPM
Pulling force: 9KG/1000 Meter
altitude Cylinder arrangement: Single
Fuel: Gasoline + 2T synthetic oil
Lubrication Ratio: 25:1~30: 1(trial run) 40: 1~50:1(normal flying) 92# 93# gasoline 2T
Compression Ratio: 8:1
Propeller Recommended: 18*10 , 19*10 , 19*8 , 20*8
Spark Plug: DLA CM6,Iridium
Voltage: 6.6v-8.4v, 2 LiPo batteries recommended.
Weight: Main engine: 1360g ,
Exhaust pipe: 127g , Ignition: 135g ,standoffs: 32*4g
Customization: According to Customer’s need and specifications
