Silicon Nitride Ceramic Heater Protection Tube - High-Performance Heat & Corrosion Resistant Heater Protective Tube
Silicon Nitride Ceramic Heater Protection Tube - High-Performance Heat & Corrosion Resistant Heater Protective Tube
Silicon Nitride Ceramic Heater Protection Tube - High-Performance Heat & Corrosion Resistant Heater Protective Tube
Silicon Nitride Ceramic Heater Protection Tube - High-Performance Heat & Corrosion Resistant Heater Protective Tube
Silicon Nitride Ceramic Heater Protection Tube - High-Performance Heat & Corrosion Resistant Heater Protective Tube
Silicon Nitride Ceramic Heater Protection Tube - High-Performance Heat & Corrosion Resistant Heater Protective Tube
Specifications
Brand Name :
KeGu
Model Number :
Customizable
Place of Origin :
China
Price :
200-500 yuan/kg
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
2,000 pcs/month
Packaging Details :
Strong wooden box for Global shipping
Density :
>3.2g/cm3
Apparent Porosity :
0-0.1%
Elastic Modulus :
300-320GPa
Vickers hardness(HV0.5) :
15-16GPa
Bending Strength :
>700MPa
Thermal conductivity :
20-25W/(m.k)
Description
Silicon Nitride Ceramic Heater Protection Tube - High-Performance Heat & Corrosion Resistant Heater Protective Tube


Description:


The Silicon Nitride Ceramic Heater Protection Tube is crafted from advanced ceramic materials, specifically designed to safeguard heater elements. With its exceptional thermal conductivity, high-temperature resistance, and corrosion resistance, it effectively prevents heater erosion during non-ferrous metal smelting, significantly enhancing the heater's service life and reliability while ensuring uniform heating of the molten metal, thereby improving production efficiency.


Typical application:


  • Heater Protection: Prevents heater damage in high-temperature and corrosive environments.
  • Uniform Heating: Ensures even heating of molten metal, enhancing product quality.
  • Widely Used In: Non-ferrous metal smelting, heat treatment, chemical, electronics, and other industries.


Feature:


  • Excellent in mechanical properties
  • Outstanding thermal shock resistance
  • Superior corrosion resistance for longer service life
Silicon Nitride Ceramic Heater Protection Tube - High-Performance Heat & Corrosion Resistant Heater Protective Tube


The physical properties of gps silicon nitride products:


Item Unit Result
Density g/cm3 3.20-3.26
Apparent porosity % 0-0.1
Elastic modulus GPa 300-320
Compression strength MPa > 1500
Vickers hardness(HV0.5) GPa 15-16
Fracture toughness MPa.m1/2 >8.0
Bending strength MPa >700
Poisson's ratio - 0.25
Linear expansion coefficient x10-6/°C 3.1-3.3
Weibull modulus - 11-13
Thermal conductivity W/(m.k) 20-25
Specific resistivity Ω·cm 104

Available product sizes:


Max. diameter is 430mm and max. length is 1350mm. It can be customized as per customers' requests.
